4V420-15 Airtac Type Pneumatic Air Solenoid Valve 5 Way 2 Postion 24V 220V

Large Image : 4V420-15 Airtac Type Pneumatic Air Solenoid Valve 5 Way 2 Postion 24V 220V

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	4V420-15

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	Negotiation
Packaging Details:	Individual box, Carton, Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T, PayPal, Western Union
Supply Ability:	200000 pcs per month

Contact Now

Detailed Product Description

Type:	5/2 Way, Double Solenoid	Port Size:	In=Out=Exhaust=1/2''
Pressure Range:	0.15 To 0.8MPa (21 To 114PSI)	Max Pressure Resistance:	1.5MPa (215PSI)
Body Material:	Aluminum Alloy	Max. Frequency:	3 Cycle / Second
Highlight:	Air Solenoid Valve 5 Way 2 Postion , Pneumatic Air Solenoid Valve 24V , 4V420-15 Airtac

4V420-15 Airtac Type Pneumatic Air Solenoid Valve 5 Way 2 Postion 24V 220V

Pneumatic solenoid valves can be found in a wide range of industries. They are used in Pneumatic Artificial Muscles (PAM) for robotics and automation. Manufacturing companies that use conveyors belts uses pneumatic valves in their conveyor belt systems. Food and beverage manufacturers use them to make, dispense or preserve food and beverage products.

BRNADO pneumatic valves offer reliability, low power consumption, and have a long life. They are have prewired connections that makes installation, maintenance, and control simple.

Technical Data of 4V400 Series Pneumatic Solenoid Valves:

Model	4v410-15	4V420-15	4V430C-15	4V430E-15	4V430P-15
Fluid	Air (to be filtered by 40 μ m filter element)
Acting	Internal Pilot or External Pilot
Port Size	In=Out=Exhaust=1/2''
Orifice Size	50.00 mm² (Cv=2.79)		30.00 mm² (Cv=1.68)
Valve Type	5 Way 2 Position		5 Way 3 Position
Operating Pressure	0.15~0.8 MPa (21~114 psi)
Proof	1.5 MPa (215 psi)
Temperature ℃	-20 to 70
Material of Body	Aluminum Alloy
Max. Frequency	3cycle/sec

Dimension of 4V420-15 Pneumatic Solenoid Valve:

4V420-15 Airtac Type Pneumatic Air Solenoid Valve 5 Way 2 Postion 24V 220V 0

Product video of 4V420-15 Pneumatic Solenoid Valve:

Production Video of Pneumatic Solenoid Valve:

More Pneumatic Products for you to choose:

4V420-15 Airtac Type Pneumatic Air Solenoid Valve 5 Way 2 Postion 24V 220V 1

Solenoid Operator Manifold Silencer Pneumatic Hose Fittings

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
