4V310-08 Airtac Type Solenoid Pneumatic Valve 5/2 Way 24V DC 220V AC

4V310-08 Airtac Type Solenoid Pneumatic Valve 5/2 Way 24V DC 220V AC

  • 4V310-08 Airtac Type Solenoid Pneumatic Valve 5/2 Way 24V DC 220V AC
4V310-08 Airtac Type Solenoid Pneumatic Valve 5/2 Way 24V DC 220V AC
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 4V310-08
Payment & Shipping Terms:
Minimum Order Quantity: 200 PCS
Packaging Details: Individual box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Type: 5/2 Way, Single Solenoid Port Size: In=Out=Exhaust=1/4''
Pressure Range: 0.15 To 0.8MPa (21 To 114PSI) Max Pressure Resistance: 1.5MPa (215PSI)
Body Material: Aluminum Alloy Max. Frequency: 5 Cycle / Second
High Light:

Pneumatic Valve 5/2 Way Solenoid

,

Pneumatic Solenoid Valve 24V DC

,

4V310-08 Airtac

4V310-08 Airtac Solenoid Pneumatic Valve 5/2 Way 24V DC 220V AC



Pneumatic solenoid valve for air, 5 way 2 position - 5/2 way, single solenoid, is available for voltages 12VDC, 24VDC, 110VAC or 220VAC, pilot-operated mode, port size 1/8'', 1/4'', 3/8'', 1/2'' for your options, fast and safe switching on/off. It is widely used in the chemical, petroleum, pharmaceutical, automotive, light industry, food, mineral processing, water treatment, electroplating, metallurgy, dyes, textiles and so on. BRANDO pneumatic valves are reliable, low power consuming, and have long life. They are have prewired connections that makes installation, maintenance, and control easy.



Data of 4V300 Series Pneumatic Solenoid Valves:

Model
4V310-08
4V320-08
4V330C-08
4V330E-08
4V330P-08
4V310-10
4V320-10
4V330C-10
4V330E-10
4V330P-10
Fluid
Air(to be filtered by 40 μ m filter element)
Acting
Internal pilot or external pilot
Port Size
In=Out=Exhaust=1/4''
In=Out=3/8'' Exhaust=1/4''
Orifice Size
25.00 mm2 (Cv=1.40)
18.00 mm2 (Cv=1.00)
30.00 mm2 (Cv=1.68)
18.00 mm2 (Cv=1.00)
Valve Type
5 port 2 position
5 port 3 position
5 port 2 position
5 port 3 position
Operating Pressure
0.15~0.8MPa(21~114psi)
Proof Pressure
1.5MPa(215psi)
Temperature ℃
-20~70
Material of Body
Aluminum alloy
Max. frequency
4 cycle/sec
4 cycle/sec
4 cycle/sec
4 cycle/sec


Dimension of 4V310-08 Pneumatic Solenoid Valve:

4V310-08 Airtac Type Solenoid Pneumatic Valve 5/2 Way 24V DC 220V AC 0



Product video of 4V310-08 Pneumatic Solenoid Valve:


Production Video of Pneumatic Solenoid Valve:



More Pneumatic Products for you to choose:

4V310-08 Airtac Type Solenoid Pneumatic Valve 5/2 Way 24V DC 220V AC 14V310-08 Airtac Type Solenoid Pneumatic Valve 5/2 Way 24V DC 220V AC 24V310-08 Airtac Type Solenoid Pneumatic Valve 5/2 Way 24V DC 220V AC 3pneumatic fast fittings

      Solenoid Operator                                 Manifold                                    Silencer                        Pneumatic Hose Fittings



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
