4V120-06 Airtac Type Pneumatic Double Solenoid Valve 5/2 Way 24V 220V

4V120-06 Airtac Type Pneumatic Double Solenoid Valve 5/2 Way 24V 220V

4V120-06 Airtac Type Pneumatic Double Solenoid Valve 5/2 Way 24V 220V
video
4V120-06 Airtac Type Pneumatic Double Solenoid Valve 5/2 Way 24V 220V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 4V120-06
Payment & Shipping Terms:
Minimum Order Quantity: 200pcs
Price: Negotiation
Packaging Details: Individual box, Carton, Pallet
Delivery Time: 15 working days
Payment Terms: T/T, PayPal, Western Union
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Type: 5/2 Way, Double Solenoid Port Size: In=Out=1/8''
Pressure Range: 0.15 To 0.8MPa (21 To 114PSI) Max Pressure Resistance: 1.5MPa (215PSI)
Body Material: Aluminum Alloy Max. Frequency: 5 Cycle / Second
High Light:

Pneumatic Double Solenoid Valve

,

Pneumatic Solenoid Valve 5/2 Way

,

4V120-06 Airtac

4V120-06 Airtac Type Pneumatic Double Solenoid Valve 5/2 Way 24V 220V



Pneumatic solenoid valves are used to direct or stop the flow of compressed air to their appliances. They can be used for example to actuate a cylinder, a larger industrial valve or air tools. Directional control valves are generally classified by two numbers, the first digit indicates the number of ports, the second digit the number of states. The most common types are 3/2-way, 5/2-way and 5/3-way. The valves can be single or double acting (one or two solenoids). By changing the solenoid coil, different operating voltages can be achieved. Several models are prepared for manifold mouning, please note the platform size when selecting a valve and manifold. Optionally, the valve body has a Namur configuration to directly mount the valve onto the actuator.



Data of 4V100 Series Pneumatic Solenoid Valves:

Model
4V110-06
4V120-06
4V130C-06
4V130E-06
4V130P-06
4V110-08
4V120-08
4V130C-08
4V130E-08
4V130P-08
Fluid
Air(to be filtered by 40 μ m filter element)
Acting
Internal pilot or external pilot
Port Size
In=Out=1/8''
In=Out=1/4''
Orifice Size
5.5 mm2
(Cv=0.31)
5.0 mm2
(Cv=0.28)
12.00 mm2
(Cv=0.67)
9.00 mm2 (Cv=0.50)
Valve Type
5 port 2 position
5 port 3 position
5 port 2 position
5 port 3 position
Operating Pressure
0.15~0.8MPa (21~114psi)
Proof Pressure
1.5MPa (215psi)
Temperature ℃
-20~70
Material of Body
Aluminum alloy
Max. frequency
5 cycle/sec
3 cycle/sec
5 cycle/sec
3 cycle/sec



Dimension of 4V120-06 Pneumatic Solenoid Valve:

4V120-06 Airtac Type Pneumatic Double Solenoid Valve 5/2 Way 24V 220V 0


Production Video of Pneumatic Solenoid Valve:



More Pneumatic Products for you to choose:

4V120-06 Airtac Type Pneumatic Double Solenoid Valve 5/2 Way 24V 220V 14V120-06 Airtac Type Pneumatic Double Solenoid Valve 5/2 Way 24V 220V 24V120-06 Airtac Type Pneumatic Double Solenoid Valve 5/2 Way 24V 220V 3pneumatic fast fittings

      Solenoid Operator                                 Manifold                                    Silencer                        Pneumatic Hose Fittings
