4M210-08 Airtac Type Namur Solenoid Valve 5/2 Way G1/4'' 24V 220V

4M210-08 Airtac Type Namur Solenoid Valve 5/2 Way G1/4'' 24V 220V

4M210-08 Airtac Type Namur Solenoid Valve 5/2 Way G1/4'' 24V 220V
video
4M210-08 Airtac Type Namur Solenoid Valve 5/2 Way G1/4'' 24V 220V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 4M210-08
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: $3 to $ 5 per pc
Packaging Details: Individual box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Valve Type: 5 Way 2 Position Port Size: In=Out=1/4''
Pressure Range: 0.15 To 0.8MPa (21 To 114PSI) Max Pressure Resistance: 1.5MPa (215PSI)
Body Material: Aluminum Alloy Max. Frequency: 5 Cycle / Second
Voltages: 220V AC, 110V AC, 24V AC, 24V DC, 12V DC
High Light:

Solenoid Valve 4M210-08

,

Namur Solenoid Valve 5/2

,

4M210-08 Airtac

4M210-08 Airtac Type Namur Solenoid Valve 5/2 Way G1/4'' 24V 220V



Aluminum Alloy 5 way 2 position namur solenoid valve. G1/4'' port size, 5℃ to 80 ℃ Media temperatur. Class F insulation, 4.8 Watts coil power, IP65 coil protection. The solenoid valve with 5 position 2 positions with namur interface makes it suitable for attaching directly to the pneumatic actuator (both in operation and back to the spring). Standard features include manual override, indicator plug (IP65), encapsulated low voltage coil (AC 5.5 VA, DC 4.8 Watts). Available in all voltages. Comes with mounting screws.



Data of NAMUR Pneumatic Solenoid Valves:

Model No

4M110-M5

4M120-M5

4M110-06

4M120-06

4M210-06

4M220-06

4M210-08

4M220-08

4M310-08

4M320-08

4M310-10

4M320-10

Fluid Air (to be filtered by 40 μm filter element)
Port Size In=Out=M5 In=Out=1/8'' In=Out=1/8'' In=Out=1/4'' In=Out=1/4'' In=Out=3/8''
Orifice Size

5.5mm²

(Cv=0.31)

12.0mm²

(Cv=0.67)

14.0mm²

(Cv=0.78)

16.0mm²

(Cv=0.89)

25.0mm²

(Cv=1.40)

30.0mm²

(Cv=1.67)

Valve Type 5 Way 2 Position
Operating Pressure 0.15 to 0.8MPa (21 to 114 PSI)
Proof Pressure 1.5MPa (215PSI)
Temperature (℃) -20 to +70
Body Material Aluminum Alloy
Max. Frequency 5 Cycle / Second 4 Cycle / Second
Coil Voltages 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Coil Protection Class IP65
Activating Time 0.05 second and below



Dimension of 4M210-08 Namur Solenoid Valve:

4M210-08 Airtac Type Namur Solenoid Valve 5/2 Way G1/4'' 24V 220V 0
