| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 3V310-10 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | $3 to $ 5 per pc |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4 to 7 working days |
| Payment Terms: | L/C, T/T, PayPal, Western Union, MoneyGram |
| Supply Ability: | 200000 pcs per month |
| Fluids: | Air (to Be Filtered By 40 μ M Filter Element) | Acting: | Internal Pilot Or External Pilot |
|---|---|---|---|
| Valve Type: | 3 Way 2 Position | Port Size: | 3/8'' |
| Pressure Range: | 0.15 To 0.8MPa | Max Pressure Resistance: | 1.5MPa |
| Body Material: | Aluminum Alloy | Voltage: | 12VDC, 24VDC, 110VAC, 220VAC |
| High Light: | 3V310-10-NO Solenoid Valve,Pneumatic Solenoid Valve 3 Way 2 Position,3V310-10-NO Airtac |
||
3V310-10-NO Airtac Type Pneumatic Solenoid Valve 3 Way 2 Position
The 3V310-10 is a pneumatic directional solenoid valve with a three-way operation & three ports (P = Pressure, A = Outlet, EA = Exhaust for port A). Three-way, two-position valves are generally used to fully extend a single acting (spring return) cylinder, or in applications with similar operation.
Technical Data of 3V300 Series Pneumatic Solenoid Valves:
| Model No |
3V310-08 |
3V320-08 |
3V310-10 |
3V320-10 |
| Fluid | Air (to be filtered by 40 μm filter element) | |||
| Port Size | In=Out=1/4'' | In=Out=3/8'' | ||
| Orifice Size |
25.0mm² (Cv=1.39) |
30.0mm² (Cv=1.67) |
||
| Valve Type | 3 Way 2 Position | |||
| Operating Pressure | 0.15 to 0.8MPa (21 to 114 PSI) | |||
| Proof Pressure | 1.5MPa (215PSI) | |||
| Temperature (℃) | -20 to +70 | |||
| Body Material | Aluminum Alloy | |||
| Coil Voltages | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | |||
| Coil Protection Class | IP65 | |||
| Activating Time | 0.05 second and below | |||
Dimension of 3V310-10 Pneumatic Solenoid Valve:
Production Video of Pneumatic Solenoid Valves:
More Pneumatic Products for you to choose:
2/2 Way 3/2 Way 5/2 Way, Single Solenoid
5/2 Way, Double Solenoid 5/3 Way, Double Solenoid Pneumatic Hose Fittings
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
