3V310-10-NC Airtac Type Pneumatic Solenoid Valve 3/2 Way 220V 24V

3V310-10-NC Airtac Type Pneumatic Solenoid Valve 3/2 Way 220V 24V

3V310-10-NC Airtac Type Pneumatic Solenoid Valve 3/2 Way 220V 24V
video
3V310-10-NC Airtac Type Pneumatic Solenoid Valve 3/2 Way 220V 24V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 3V310-10
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: $3 to $ 5 per pc
Packaging Details: Individual box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Fluids: Air (to Be Filtered By 40 μ M Filter Element) Acting: Internal Pilot Or External Pilot
Valve Type: 3 Way 2 Position Port Size: 3/8''
Pressure Range: 0.15 To 0.8MPa Max Pressure Resistance: 1.5MPa
Body Material: Aluminum Alloy Voltage: 12VDC, 24VDC, 110VAC, 220VAC
High Light:

3V310-10-NC Solenoid Valve

,

Pneumatic Solenoid Valve 3/2 Way

,

3V310-10-NC Airtac

3V310-10-NC Airtac Type Pneumatic Solenoid Valve 3/2 Way 220V 24V



3 way pneumatic solenoid valves are the same as 2 way pneumatic solenoid valves with the addition of a third port for exhausting downstream air. 3 way pneumatic solenoid valves are available in a normally open or normally closed operating configurations. These valves are used to control single acting or spring return cylinders and any load which must be pressurized and alternately exhausted. These valves can also pilot other air operated valves.



Technical Data of 3V300 Series Pneumatic Solenoid Valves:

Model No

3V310-08

3V320-08

3V310-10

3V320-10

Fluid Air (to be filtered by 40 μm filter element)
Port Size In=Out=1/4'' In=Out=3/8''
Orifice Size

25.0mm²

(Cv=1.39)

30.0mm²

(Cv=1.67)

Valve Type 3 Way 2 Position
Operating Pressure 0.15 to 0.8MPa (21 to 114 PSI)
Proof Pressure 1.5MPa (215PSI)
Temperature (℃) -20 to +70
Body Material Aluminum Alloy
Coil Voltages 12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Coil Protection Class IP65
Activating Time 0.05 second and below


Dimension of 3V310-10 Pneumatic Solenoid Valve:
3V310-10-NC Airtac Type Pneumatic Solenoid Valve 3/2 Way 220V 24V 0


Production Video of Pneumatic Solenoid Valves:


More Pneumatic Products for you to choose:

3V310-10-NC Airtac Type Pneumatic Solenoid Valve 3/2 Way 220V 24V 13V310-10-NC Airtac Type Pneumatic Solenoid Valve 3/2 Way 220V 24V 24v210-08
                    2/2 Way                                      3/2 Way                5/2 Way, Single Solenoid
a1a1pneumatic fast fittings
  5/2 Way, Double Solenoid     5/3 Way, Double Solenoid       Pneumatic Hose Fittings
