Name: Korea Joil Type 1-1/2'' Inch Pulse Jet Diaphragm Valve Membrane Set
Brand: Brando
SKU: J40
Rating: 4.8 (125 reviews)

Home Products Diaphragm Repair Kit

Korea Joil Type 1-1/2'' Inch Pulse Jet Diaphragm Valve Membrane Set

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	J40

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Plastic Bags, Cartons, Pallet
Delivery Time:	4-7 Days
Payment Terms:	L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability:	200000 pcs per month

Contact Now

Detailed Product Description

Name:	Diaphragm Repair Kit	Applicable Valves:	JICI 40, JICR 40, JISI 40, JISR 40, JIFI 40, JIFR 40
Diaphragm Material:	NBR (Buna)	Mounting Hole Size:	φ8.5mm
Diaphragm Outer Diameter:	φ109.0mm	Hole Center Distance:	φ103.5mm
Seat Material:	NBR (Buna)	Seat OD:	φ58.5mm
Seat ID:	φ34.0mm	Bleed Hole:	1
Packaging:	Individual Plastic Bag Sealed
High Light:	Korea Joil Type Membrane Set , 1-1/2'' Inch Membrane Set , Joil 1.5 Inch Diaphragm

Korea Joil Type 1-1/2'' Inch Pulse Jet Diaphragm Valve Membrane Set

This is repair kit NBR diaphragm, used in Joil 1 1/2" JICI 40, JICR 40, JISI 40, JISR 40, JIFI 40, JIFR 40 diaphragm pulse valves. One set of diaphragm kit includes one buna seat buna diaphragm and one small stainless steel spring. The diaphragm is the key component in diaphragm pulse jet valves. It is one of the fittings for the normal operation of the valve body and the "switch" of the injection air circuit of the dust cleaning system of the pulse bag filter. It can easily ensure complete synchronization with other control components to control the injection of pulsed compressed air. So the tightness and softness of the diaphragm play a decisive role in the blowing effect of the pulse valve.

Due to pulse valve diaphragm needs from time to time opening and closing action is a flexible mechanism to control the air circulation, has good flexibility and requirements, also demanded the sealing as high as possible, so the pulse valve diaphragm material is directly related to the service life of pulse valve diaphragm and using effect, in other words, the pulse valve diaphragm is good or bad will directly affect the working stability of pulse bag filter soot cleaning system, is directly related to the use of dust removal equipment cost, the service life of the general pulse valve diaphragm has or the number of times

YouTube video of Diaphragm Repair Kit For 1 1/2'' Joil Pulse Valve:

Main dimension of JICI/JICR 40 JISI/JISR 40 JIFI/JIFR 40 Diaphragm:

Korea Joil Type 1-1/2'' Inch Pulse Jet Diaphragm Valve Membrane Set 0

Details display of 1.5'' JICI/JICR JISI/JISR JIFI/JIFR Valve Diaphragm:

Korea Joil Type 1-1/2'' Inch Pulse Jet Diaphragm Valve Membrane Set 1

Available Models of Diaphragm Valve Repair Kits For Joil Pulse Valves:

Ordering Code	Type	Quatity	Suitable valve	Material
J20	3/4''	1	JICI 20, JICR 20, JISI 20, JISR 20	Nitrile/Buna
J25	1''	1	JICI 25, JICR 25, JISI 25, JISR 25
J40 & JTY-X	1 1/2''	2	JICI 40, JICR 40, JISI 40, JISR 40, JIFI 40, JIFR 40
J50 & JTY-X	2''	2	JISI 50, JISR 50, JIFI 50, JIFR 50
J76 & JTY-X	2 1/2''	2	JISI 65, JISR 65, JIFI 65, JIFR 65
J89 & JTY-X	3''	2	JISI 80, JISR 80, JIHI 80, JIHR 80
J102 & JTY-X	4''	2	JIHI 100, JIHR 100
