Airtac Type Pneumatic Air Pilot Valve 5 Way 2 Postion 5 Way 3 Position

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	4A

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Individual box, Carton, Pallet
Delivery Time:	Negotiation
Payment Terms:	T/T, PayPal, Western Union
Supply Ability:	200000 pcs per month

Contact Now

Detailed Product Description

Type:	5/2 Way, 5/3 Way	Port Size:	M5, 1/8'', 1/4'', 3/8'', 1/2''
Pressure Range:	0.15 To 0.8MPa (21 To 114PSI)	Max Pressure Resistance:	1.5MPa (215PSI)
Body Material:	Aluminum Alloy	4A100 Series:	4A110-M5, 4A110-06, 4A120-M5, 4A120-06, 4A130C-M5, 4A130C-06, 4A130E-M5, 4A130E-06, 4A130P-M5, 4A130P-06
4A200 Series:	4A210-06, 4A210-08, 4A220-06, 4A220-08, 4A230C-06, 4A230C-08, 4A230E-06, 4A230E-08, 4A230P-06, 4A230P-08	4A300 Series:	4A310-08, 4A310-10, 4A320-08, 4A320-10, 4A330C-08, 4A330C-10, 4A330E-08, 4A330E-10, 4A330P-08, 4A330P-10
4A400 Series:	4A410-15, 4A420-15, 4A430C-15, 4A430E-15, 4A430P-15
Highlight:	5 Way Air Pilot Valve , Pneumatic Air Pilot Valve , Airtac Air Valve

Airtac Type Pneumatic Air Pilot Valve 5 Way 2 Postion 5 Way 3 Position

Product features of Pneumatic Air Pilot Valve:

1. Structure in sliding column mode: good tightness and sensitive reaction.
2. Three position air valves have three kinds of central function for your choice.
3. Double air control valves have memory function.
4. Internal hole adopts special processing technology which has lttle attrition friction, low start pressure and long service life.
5. No need to add oill for lubrication.
6. Integrate with the manifold to save installation space.

Data of 4A100 Series Pneumatic Control Valves:

Model	4A110-M5 4A120-M5	4A130C-M5 4A130E-M5 4A130P-M5	4A110-06 4A120-06	4A130C-06 4A130E-06 4A130P-06
Fluid	Air (to be filtered by 40 μ m filter element)
Acting	Exterior Control
Port Size	In=Out=M5		In=Out=1/8''
Orifice Size	5.5 mm2 (Cv=0.31)	5.0 mm2 (Cv=0.28)	12.00 mm2 (Cv=0.67)	9.00 mm2 (Cv=0.50)
Valve Type	5 port 2 position	5 port 3 position	5 port 2 position	5 port 3 position
Operating Pressure	0.15~0.8MPa (21~114psi)
Proof Pressure	1.5MPa (215psi)
Temperature ℃	-20~70
Material of Body	Aluminum alloy
Max. frequency	5 cycle/sec	3 cycle/sec	5 cycle/sec	3 cycle/sec

Data of 4A200 Series Pneumatic Control Valves:

Model	4A210-06 4A220-06	4A230C-06 4A230E-06 4A230P-06	4A210-08 4A220-08	4A230C-08 4A230E-08 4A230P-08
Fluid	Air (to be filtered by 40 μ m filter element)
Acting	Exterior Control
Port Size	In=Out=Exhaust=1/8''		In=Out=1/4'', Exhaust=1/8''
Orifice Size	25.00 mm2 (Cv=0.78)	18.00 mm2 (Cv=0.67)	30.00 mm2 (Cv=0.89)	18.00 mm2 (Cv=0.67)
Valve Type	5 way 2 position	5 way 3 position	5 way 2 position	5 way 3 position
Working Pressure	0.15~0.8MPa (21~114psi)
Max. Pressure Resistance	1.5MPa (215psi)
Temperature	5~50 ℃
Material of Body	Aluminum Alloy
Max. frequency	5 cycle/sec

Data of 4A300 Series Pneumatic Control Valves:

Model	4A310-08 4A320-08	4A330C-08 4A330E-08 4A330P-08	4A310-10 4A320-10	4A330C-10 4A330E-10 4A330P-10
Fluid	Air (to be filtered by 40 μ m filter element)
Acting	Exterior Control
Port Size	In=Out=Exhaust=1/4''		In=Out=3/8'' Exhaust=1/4''
Orifice Size	25.00 mm2 (Cv=1.40)	18.00 mm2 (Cv=1.00)	30.00 mm2 (Cv=1.68)	18.00 mm2 (Cv=1.00)
Valve Type	5 port 2 position	5 port 3 position	5 port 2 position	5 port 3 position
Operating Pressure	0.15~0.8MPa (21~114psi)
Proof Pressure	1.5MPa (215psi)
Temperature ℃	-20~70
Material of Body	Aluminum alloy
Max. frequency	4 cycle/sec	4 cycle/sec	4 cycle/sec	4 cycle/sec

Data of 4A400 Series Pneumatic Control Valves:

Model	4A410-15	4A420-15	4A430C-15	4A430E-15	4A430P-15
Fluid	Air (to be filtered by 40 μ m filter element)
Acting	Exterior Control
Port Size	In=Out=Exhaust=1/2''
Orifice Size	50.00 mm² (Cv=2.79)		30.00 mm² (Cv=1.68)
Valve Type	5 port 2 position		5 port 3 position
Operating Pressure	0.15~0.8MPa (21~114psi)
Proof	1.5MPa (215psi)
Temperature ℃	-20 to 70
Material of Body	Aluminum alloy
Max. frequency	3cycle/sec

Production Video of Pneumatic Solenoid Valve:

More Pneumatic Products for you to choose:

Airtac Type Pneumatic Air Pilot Valve 5 Way 2 Postion 5 Way 3 Position 0 pneumatic fast fittings

Manifold Silencer Pneumatic Hose Fittings

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
