Goyen Type RCAC25 Pulse Jet Valve 1'' Inch K2529 Buna Diaphragm Repair Kit

Goyen Type RCAC25 Pulse Jet Valve 1'' Inch K2529 Buna Diaphragm Repair Kit


This is K2529 25 millennium buna diaphragm kit, used in Goyen 1" RCAC25T3, RCAC25DD3, RCAC25FS3 diaphragm valves. One set of K2529 diaphragm kit includes one Nylon seat buna diaphragm and one small stainless steel spring. The diaphragm is the key component in diaphragm pulse jet valves. It is one of the fittings for the normal operation of the valve body and the "switch" of the injection air circuit of the dust cleaning system of the pulse bag filter. It can easily ensure complete synchronization with other control components to control the injection of pulsed compressed air. So the tightness and softness of the diaphragm play a decisive role in the blowing effect of the pulse valve.

YouTube video of Goyen Type K2529 25 Millennium Buna Diaphragm Kit:


Main dimension of Goyen Type K2529 25 Millennium Diaphragm Repair Kit:


Details display of K2529 Goyen Type RCAC25 Diaphragm Valve Repair Kit:


Available Models of Goyen Type 1'' RCA/RCAC Diaphragm Valve Repair Kits:

Tips: The valves mentioned, related solenoid coils and armature assembly are all supplied.

Diaphragm Features:

1. Diaphragm (Rubber or Fabric Reinforcement in Rubber Diaphragms) is a precision functional part used check pressure or change fluid pressure into drive power.

2. Fabric-reinforced in rubber diaphragms utilize a layer of an engineered fabric material as part of the diaphragm comstruction. This layer of fabric give tremendous design flexibity.

3. Fabric is made of polyester, nylon and silk and commonly used for most applications, such like exposed to high-temperature, or require extremely high-strength.

4. Facbric-reinforced diaphragms advantages:
* No leakage * No Lubrication * No Breakaway Force * No Friction
* Functionality Over Wide Pressure Ranges
* High Strength * Low Cost * Simple Design * Versatility

5. EPDM, Viton all available.

Tips:
1. Before conducting any maintenance activity on the system ensure that components are fully isolated from pressure and power supplies. Pressure and power should not be reapplied until the valve has been fully assembled.

2. Diaphragm and pilot inspection should be conducted annually.
