Name: Old Version DMF-Z-76S DMF-T-76S DMF-ZM-76S DMF-Y-76S 3'' Inch Nitrile Diaphragm Set
Brand: Ningbo Brando Hardware Co., Ltd
SKU: LD76
Price: 49.10 USD
Availability: InStock

Home Products Diaphragm Repair Kit

Old Version DMF-Z-76S DMF-T-76S DMF-ZM-76S DMF-Y-76S 3'' Inch Nitrile Diaphragm Set

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE, ISO
Model Number:	LD76

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Price:	Negotiation
Packaging Details:	Plastic Bags, Cartons, Pallet
Delivery Time:	4-7 Days
Payment Terms:	L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability:	200000 pcs per month

Contact Now

Detailed Product Description

Diaphragm Material:	NBR/Buna	Suitable Valve Number:	DMF-Z-76S DMF-T-76S DMF-ZM-76S DMF-Y-76S
Mounting Hole Size:	8.5mm	Diaphragm Outer Distance:	201mm
Center Distance:	182mm	Spring:	With
Packaging:	Individual Sealed	Diaphragm Seat OD:	102mm
Diaphragm Seat ID:	50mm
Highlight:	Old Version Nitrile Diaphragm Set , 3'' Inch Nitrile Diaphragm Set , Old Version 3'' Inch Membrane

Old Version DMF-Z-76S DMF-T-76S DMF-ZM-76S DMF-Y-76S 3'' Inch Nitrile Diaphragm Set

Dmf-y submerged valve diaphragm, that is, three inch submerged valve matching diaphragm, submerged valve diaphragm is an important part of submerged electromagnetic pulse valve, the quality of submerged valve diaphragm plays a decisive role in the service life of submerged electromagnetic pulse valve. Our company produces various specifications of submerged valve diaphragm, from the small one and a half inch submerged valve to submerged 80 pulse valve diaphragm. With neat appearance and reliable quality, it is one of the favorite products of the manufacturer; the pulse valve diaphragm mould is complete, up to thousands of kinds, and produces various special diaphragms for high temperature, strong acid and alkali resistant environment.

Main dimension of BFEC Replacement Diaphragm Repair Kits:

Old Version DMF-Z-76S DMF-T-76S DMF-ZM-76S DMF-Y-76S 3'' Inch Nitrile Diaphragm Set 0

Available Models of SBFEC Type DMF/MF Diaphragm Valve Repair Kits:

Ordering Code	Fitted Valve Code	Port Size
DTY	MF/DMF-T-25S, MF/DMF-T-40S, MF/DMF-T-50S, MF/DMF-T-62S, MF/DMF-ZM-40S, MF/DMF-Y-40S, MF/DMF-Y-50S, MF/DMF-Y-62S, MF/DMF-Y-76S, MF/DMF-YA-76S, MF/DMF-YB-76S, MF/DMF-Y-102S, MF/DMF-Y-102SA, MF/DMF-Y-102SE, MF/DMF-ZF-40S, MF/DMF-Z-40S, MF/DMF-Z-50S, MF/DMF-Z-62S, MF/DMF-Z-76S, MF/DMF-Z-102S	Tip: Secondary Diaphragm
D20A	DMF-Z-20, MF-Z-20, DMF-ZM-20, MF-ZM-20	3/4''
D25	DMF-Z-25, MF-Z-25, DMF-ZM-25, MF-ZM-25, DMF-ZF-25, MF-ZF-25, DMF-Y-25, MF-Y-25, DMF-T-20, MF-T-20	3/4'' & 1''
D40	DMF-Z-40S, MF-Z-40S, DMF-Y-40S, MF-Y-40S, DMF-ZF-40S, MF-ZF-40S, DMF-ZM-40S, MF-ZM-40S, DMF-T-25S, MF-T-25S	1'' & 1-1/2''
D50	DMF-Z-50S, MF-Z-50S, DMF-Y-50S, MF-Y-50S, DMF-T-50S, MF-T-50S	2''
D62	DMF-Z-62S, MF-Z-62S, DMF-Y-62S, MF-Y-62S	2-1/2''
D76	DMF-Z-76S, MF-Z-76S, DMF-Y-76S, MF-Y-76S	3''
D102	DMF-Z-102S, MF-Z-102S, DMF-Y-102S, MF-Y-102S	4''
D102A	DMF-Y-102SA, MF-Y-102SA	4''
DZL-20B	DMF-ZL-B, MF-ZL-B	3/4''

Tips: The valves mentioned, related solenoid coils and armature assembly are all supplied.

Application Examples:

Old Version DMF-Z-76S DMF-T-76S DMF-ZM-76S DMF-Y-76S 3'' Inch Nitrile Diaphragm Set 1

YouTube video of SBFEC Type NBR Diaphragm Valve Repair Kit:

Factory Production Pictures of Solenoid Valve Diaphragm Kits:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!
