5/2 Way Single Solenoid Pneumatic Solenoid Valve 5 Way 2 Position

5/2 Way Single Solenoid Pneumatic Solenoid Valve 5 Way 2 Position

5/2 Way Single Solenoid Pneumatic Solenoid Valve 5 Way 2 Position
5/2 Way Single Solenoid Pneumatic Solenoid Valve 5 Way 2 Position

Product Details:

Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 4V

Payment & Shipping Terms:

Minimum Order Quantity: 1 pc
Price: $3 to $ 5 per pc
Packaging Details: Individual box, Carton, Pallet
Delivery Time: 4 to 7 working days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Type: 5/2 Way, Single Solenoid Port Size: M5, 1/8'', 1/4'', 3/8'', 1/2''
Pressure Range: 0.15 To 0.8MPa (21 To 114PSI) Max Pressure Resistance: 1.5MPa (215PSI)
Body Material: Aluminum Alloy Max. Frequency: 5 Cycle / Second
4V100 Series: 4V110-M5, 4V110-08 4V200 Series: 4V210-06, 4V210-08
4V300 Series: 4V310-08, 4V310-10 4V400 Series: 4V410-15
High Light:

Pneumatic Solenoid Valve 5 Way 2 Position

,

Pneumatic Solenoid Valve 5/2 Way

,

Airtac Pneumatic Solenoid Valve

5/2 Way Single Solenoid Pneumatic Solenoid Valve 5 Way 2 Position



Product Features:
1. Pilot-oriented mode: optional for internal or external;
2. Structure in sliding column mode: good tightness and sensitive reaction;
3. Three position Solenoid Air Valves have three kinds of central function for your choice;
4. Double control Solenoid Air Valves have memory function;
5. Internal hole adopts special processing technology which has little attrition friction, low start pressure and long service life;
6. It is available to form integrated valve group with the base to save installation space;
7. Affiliated manual devices are equipped to facilitate installation and debugging;
8. Several standard voltage grades are optional;



Data of 4V100 Series Pneumatic Solenoid Valves:

Model
4V110-06
4V120-06
4V130C-06
4V130E-06
4V130P-06
4V110-08
4V120-08
4V130C-08
4V130E-08
4V130P-08
Fluid
Air(to be filtered by 40 μ m filter element)
Acting
Internal pilot or external pilot
Port Size
In=Out=1/8''
In=Out=1/4''
Orifice Size
5.5 mm2
(Cv=0.31)
5.0 mm2
(Cv=0.28)
12.00 mm2
(Cv=0.67)
9.00 mm2 (Cv=0.50)
Valve Type
5 port 2 position
5 port 3 position
5 port 2 position
5 port 3 position
Operating Pressure
0.15~0.8MPa (21~114psi)
Proof Pressure
1.5MPa (215psi)
Temperature ℃
-20~70
Material of Body
Aluminum alloy
Max. frequency
5 cycle/sec
3 cycle/sec
5 cycle/sec
3 cycle/sec



Data of 4V200 Series Pneumatic Solenoid Valves:

Model
4V210-06
4V220-06
4V230C-06
4V230E-06
4V230P-06
4V210-08
4V220-08
4V230C-08
4V230E-08
4V230P-08
Fluid
Air (to be filtered by 40 μ m filter element)
Acting
Internal Pilot
Port Size
In=Out=Exhaust=1/8''
In=Out=1/4'', Exhaust=1/8''
Orifice Size
25.00 mm2 (Cv=0.78)
18.00 mm2 (Cv=0.67)
30.00 mm2 (Cv=0.89)
18.00 mm2 (Cv=0.67)
Valve Type
5 way 2 position
5 way 3 position
5 way 2 position
5 way 3 position
Working Pressure
0.15~0.8MPa (21~114psi)
Max. Pressure Resistance
1.5MPa (215psi)
Temperature
5~50 ℃
Material of Body
Aluminum Alloy
Max. frequency
5 cycle/sec



Data of 4V300 Series Pneumatic Solenoid Valves:

Model
4V310-08
4V320-08
4V330C-08
4V330E-08
4V330P-08
4V310-10
4V320-10
4V330C-10
4V330E-10
4V330P-10
Fluid
Air(to be filtered by 40 μ m filter element)
Acting
Internal pilot or external pilot
Port Size
In=Out=Exhaust=1/4''
In=Out=3/8'' Exhaust=1/4''
Orifice Size
25.00 mm2 (Cv=1.40)
18.00 mm2 (Cv=1.00)
30.00 mm2 (Cv=1.68)
18.00 mm2 (Cv=1.00)
Valve Type
5 port 2 position
5 port 3 position
5 port 2 position
5 port 3 position
Operating Pressure
0.15~0.8MPa(21~114psi)
Proof Pressure
1.5MPa(215psi)
Temperature ℃
-20~70
Material of Body
Aluminum alloy
Max. frequency
4 cycle/sec
4 cycle/sec
4 cycle/sec
4 cycle/sec



Data of 4V400 Series Pneumatic Solenoid Valves:

Model
4V410-15
4V420-15
4V430C-15
4V430E-15
4V430P-15
Fluid
Air (to be filtered by 40 μ m filter element)
Acting
Internal pilot or external pilot
Port Size
In=Out=Exhaust=1/2''
Orifice Size
50.00 mm²
(Cv=2.79)
30.00 mm²
(Cv=1.68)
Valve Type
5 port 2 position
5 port 3 position
Operating Pressure
0.15~0.8MPa (21~114psi)
Proof
1.5MPa (215psi)
Temperature ℃
-20 to 70
Material of Body
Aluminum alloy
Max. frequency
3cycle/sec



Production Video of Pneumatic Solenoid Valve:



More Pneumatic Products for you to choose:

5/2 Way Single Solenoid Pneumatic Solenoid Valve 5 Way 2 Position 05/2 Way Single Solenoid Pneumatic Solenoid Valve 5 Way 2 Position 15/2 Way Single Solenoid Pneumatic Solenoid Valve 5 Way 2 Position 2pneumatic fast fittings

      Solenoid Operator                                 Manifold                                    Silencer                        Pneumatic Hose Fittings
