DMF-Z-25 DMF-Y-25 DMF-ZM-25 1'' Inch Dust Collector Valve Repair Kit

DMF-Z-25 DMF-Y-25 DMF-ZM-25 1'' Inch Dust Collector Valve Repair Kit

DMF-Z-25 DMF-Y-25 DMF-ZM-25 1'' Inch Dust Collector Valve Repair Kit
DMF-Z-25 DMF-Y-25 DMF-ZM-25 1'' Inch Dust Collector Valve Repair Kit
DMF-Z-25 DMF-Y-25 DMF-ZM-25 1'' Inch Dust Collector Valve Repair Kit
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: D25
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: Negotiation
Packaging Details: Plastic Bags, Cartons, Pallet
Delivery Time: 4-7 Days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Product Name: Diaphragm Repair Kit Mounting Hole Size: φ6.4mm
Diaphragm Material: NBR (Nitrile) Diaphragm OD: φ94.5mm
Center Distance: φ83mm Seat Material: Nylon
Seat OD: φ46mm Seat ID: φ27.5mm
Bleed Hole: 1 Spring: 1
Packaging: Individual Plastic Bag Sealed Suitable Valves: MF-Z-25, DMF-Z-25, MF-ZM-25, DMF-ZM-25 MF-Y-25, DMF-Y-25
Highlight:

DMF-Z-25 Valve Repair Kit

,

DMF-Y-25 Valve Repair Kit

,

DMF-ZM-25 Valve Repair Kit

DMF-Z-25 DMF-Y-25 DMF-ZM-25 1'' Inch Dust Collector Valve Repair Kit



Diaphragm repair kits for BFEC 1'' diaphragm pulse valve (MF-Z-25, DMF-Z-25, MF-ZM-25, DMF-ZM-25 MF-Y-25, DMF-Y-25), used for bag house dust collector. The following are some cautions:



1.Temperature:-10°C~55°C

2.The relative humidity of air not exceeding 85%

3. Service life of diaphragm:1 million times

4. Working pressure have to control from 0.2 to 0.6Mpa, and steadily.



YouTube video of 1'' DN25 BFEC NBR Diaphragm Valve Repair Kit:



Main dimension of BFEC DMF-Z-25 MF-Z-25 Diaphragm Valve Kit:

DMF-Z-25 DMF-Y-25 DMF-ZM-25 1'' Inch Dust Collector Valve Repair Kit 0



Details display of DMF/MF-ZM-25 DMF/MF-Y-20 Diaphragm Repair Kit:

DMF-Z-25 DMF-Y-25 DMF-ZM-25 1'' Inch Dust Collector Valve Repair Kit 1



Available Models of BFEC DMF/MF Diaphragm Valve Repair Kits:

Ordering Code
Fitted Valve Code
Port Size
DTY
MF/DMF-T-25S, MF/DMF-T-40S, MF/DMF-T-50S, MF/DMF-T-62S,
MF/DMF-ZM-40S, MF/DMF-Y-40S, MF/DMF-Y-50S, MF/DMF-Y-62S,
MF/DMF-Y-76S, MF/DMF-YA-76S, MF/DMF-YB-76S, MF/DMF-Y-102S,
MF/DMF-Y-102SA, MF/DMF-Y-102SE, MF/DMF-ZF-40S, MF/DMF-Z-40S,
MF/DMF-Z-50S, MF/DMF-Z-62S, MF/DMF-Z-76S, MF/DMF-Z-102S
Tip: Secondary Diaphragm
D20A
DMF-Z-20, MF-Z-20, DMF-ZM-20, MF-ZM-20
3/4''
D25
DMF-Z-25, MF-Z-25, DMF-ZM-25, MF-ZM-25,
DMF-ZF-25, MF-ZF-25, DMF-Y-25, MF-Y-25,
DMF-T-20, MF-T-20
3/4'' & 1''
D40
DMF-Z-40S, MF-Z-40S, DMF-Y-40S, MF-Y-40S,
DMF-ZF-40S, MF-ZF-40S, DMF-ZM-40S, MF-ZM-40S,
DMF-T-25S, MF-T-25S
1'' & 1-1/2''
D50
DMF-Z-50S, MF-Z-50S, DMF-Y-50S, MF-Y-50S,
DMF-T-50S, MF-T-50S
2''
D62
DMF-Z-62S, MF-Z-62S, DMF-Y-62S, MF-Y-62S
2-1/2''
D76
DMF-Z-76S, MF-Z-76S, DMF-Y-76S, MF-Y-76S
3''
D102
DMF-Z-102S, MF-Z-102S, DMF-Y-102S, MF-Y-102S
4''
D102A
DMF-Y-102SA, MF-Y-102SA
4''
DZL-20B
DMF-ZL-B, MF-ZL-B
3/4''

Tips: The valves mentioned, related solenoid coils and armature assembly are all supplied.



Factory Production Pictures of Solenoid Valve Diaphragm Kits:

34

12
