Place of Origin: | China |
Brand Name: | Brando |
Certification: | CE |
Model Number: | COMBO |
Minimum Order Quantity: | 1 pc |
---|---|
Packaging Details: | inner boxes,cartons,pallets |
Delivery Time: | 7 working days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 100000pcs per month |
Name: | COMBO Electronic Drain Valve | Valve Type: | 2/2 Way, Direct Acting |
---|---|---|---|
Port Size: | 1/8'', 1/4'', 3/8'', 1/2'' NPT | Orifice Size: | 4.5mm |
Valve Body Material: | Brass | Seal Material: | FKM |
Power Connection: | DIN 43650A | Medium Temperature Range: | 34 - 131 °F |
Applicable Industries: | Air Compressor | Strainer: | With |
High Light: | COMBO Air Compressor Automatic Drain Valve,Timed Air Compressor Automatic Drain Valve,Jorc Type Auto Drain Valve |
COMBO 1/4'' 1/2'' Timed Air Compressor Automatic Drain Valve
Pneumatic condensate auto drains can help drain condensation in your compressed air system. Choose from electronic, direct-acting, pilot-operated, pneumatic operated drain valves and more in a wide range of configurations. Trust to provide a large selection of dependable pneumatic condensate auto drains to help you find what you need.
Moisture collection and sediment buildup are the two biggest threats to your compressed air system and tools. Harmful water and sediment produced in the normal operation of air systems causes rust and corrosion to the structure if not removed from the system. These contaminates need to be drained manually or with equipment, to gain the maximum operation of the system. Excessive condensation leads to premature failure of tools and high maintenance or replacement cost.
Left to manual draining, air systems are often neglected or forgotten. Other types of automatic drains have small ports that clog up with sediment, scale and sludge. Float drain linkages immersed in steady corrosive drain solutions eventually clog and malfunction. Solenoid type drains use Y-strainers upstream that require frequent manual clean out.
Technical Data:
DIMENSION:
Dimension of OPTIMUM Type BADV01 Water Drain Valve:
Dimension of COMBO Type BADV02 Water Drain Valve:
More Details About Auto Drain Valve:
BAPC213037016 Solenoid Armture |
0200 Solenoid Coil | STRAINERS |
Feature:
Integrated mesh strainer, offering valve and orifice protection from larger particles found in condensate.
Integrated shut off valve, offering easy shut off of the valve for routine maintenance.
Dual inlet (1/2" and 1/4"), offering you installation flexibility.
A model is suitable for all applications, easy installation, fully automatic and maintenance free.
Interval time and discharge time is adjustable and have a test button.
Pressure 16 Bar, various pressure and port can be choose.
Full stain steel valve, anti-explosion valve can be choose.
CE Certificate, level of protection is IP65, insulation grade is H.
Accurate setting of drainage interval
Accurate setting of single drainage time
