SCG353A051 2-1/2'' 2.5'' Inch 353 Series Dust Collector Diaphragm Valve

SCG353A051 2-1/2'' 2.5'' Inch 353 Series Dust Collector Diaphragm Valve

  • SCG353A051 2-1/2'' 2.5'' Inch 353 Series Dust Collector Diaphragm Valve
SCG353A051 2-1/2'' 2.5'' Inch 353 Series Dust Collector Diaphragm Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: SCG353A051
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Type: Right Angle Type Diaphragm Valve Power: Solenoid
Media: Air Port Size: 2'' Inch
Structure: Diaphragm Body Material: Aluminum Alloy
Diaphragm Material: NBR(Common), FKM(Available) Number Of Diaphragm: 2
Pressure: 0.1 To 0.8MPa Temperature: -25 To +80℃
High Light:

SCG353A051 Diaphragm Valve

,

353 Series Diaphragm Valve

,

ASCO Type SCG353A051

SCG353A051 2-1/2'' 2.5'' Inch 353 Series Dust Collector Diaphragm Valve



Working principle of 353 series dust collector valves:
The two chambers of the dust collector valves are connected together through an air passage (smaller in diameter than the pilot valve orifice when so equipped). When the orifice is opened, the air in the upper chamber is exhausted, at a much faster rate than the speed of which air enters through the air passage, therfore the air pressure in the upper chamber drops significantly. As this occurs, the higher air pressure in the lower chamber pushes the diaphragm up allowing a large volume of air through to the bottom chamber and its outlet connected to the dust collector bags. This sudden burst of air inflates the filter bags or "pops" the filter bags so as to shake loose accumulated material on the outside of each filter bag. When the orifice closes, the pressure in the upper and lower chambers equalize and the diaphragm returns to its original position, aided by the force of a return spring. The dust collector valves are important components to keep dust collector systems operating efficiently and effectively.



Technical Data of ASCO Pulse Jet Valve:



Model No
SCG353A043
SCG353A044
SCG353A047
SCG353A050
SCG353A051
Port Size
G3/4''
G1''
G1-1/2''
G2''
G2-1/2''
Nominal Size
φ20mm
φ25mm
φ40mm
φ50mm
φ62mm
Working Pressure
0.3 to 0.8MPa
Environment Temperature
-5 to +55℃
Relative Humidity
≤85%
Operating Medium
Dry clean compressed air
Service Life
Over one million times
Voltages
AC24V, AC110V, AC220V, DC24V





Main Dimension:

SCG353A051 2-1/2'' 2.5'' Inch 353 Series Dust Collector Diaphragm Valve 0



353 Series Pulse Jet Valve For Dust Collector System:



Right Angle Valve
3/4''
1''
1 1/2''
2''
2 1/2''
SCG353A043
SCG353A044
SCG353A047
SCG353A050
SCG353A051
Submerged Valve
3''
SCEX353.060
Remote Pilot Valve
3/4''
1''
1 1/2''
G353A041
G353A042
G353A045
