| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | CA76MM |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Type: | Submerged Type Diaphragm Valve | Power: | Solenoid |
|---|---|---|---|
| Media: | Air | Port Size: | 3'' Inch |
| Structure: | Diaphragm | Body Material: | Aluminum Alloy |
| Diaphragm Material: | NBR(Common), FKM(Available) | Number Of Diaphragm: | 2 |
| Pressure: | 0.1 To 0.8MPa | Temperature: | -25 To +80℃ |
| High Light: | MM Series Pulse Jet Valve,Embedded Type Pulse Jet Valve,CA76MM Dust Collector Valve |
||
Goyen Type MM Series CA76MM 3'' Inch Embedded Type Pulse Jet Valve
Goyen type manifold mount pulse valve paly an important role in dust collecter system.Pulse valves are used to clean bag-type or cartridge-type filters in a dust collector system. In the production process, the generation of dust is inevitable. As particles enter the machine, it will cause damage to the equipment. Dusty air is also a hazard to workers’ health. Pulse valves are used to clean bag-type or cartridge-type filters in a dust collector system. These valves send a high-energy pulse of air through the blow tube creating a shock wave down the filters to remove dust. Higher air acceleration and quicker valve response time helps clean filter bags better and consume less compressed air, thereby lowering the cost of system operation.
Technical Data of Goyen Pulse Jet Valve:
|
Model No
|
CA25MM
|
CA40MM
|
CA50MM
|
CA62MM
|
CA76MM
|
CA102MM
|
||
|
Nominal Size
|
25
|
40
|
50
|
62
|
76
|
102
|
||
|
Port Size
|
mm
|
25
|
40
|
50
|
62
|
76
|
102
|
|
|
inch
|
1''
|
1 1/2''
|
2''
|
2 1/2''
|
3''
|
3 1/2''
|
4''
|
|
|
Pressure Range
|
0.3 to 0.8MPa
|
|||||||
|
Temp. Range
|
Nitrile seals
|
-40 to 82℃
|
||||||
|
Viton seals
|
-29 to 232℃
|
|||||||
Main Dimension:
CA RCA Series Pulse Jet Valve For Dust Collector System:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Brandon
Tel: +8613454729544
