| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | CA62MM |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Type: | Submerged Type Diaphragm Valve | Power: | Solenoid |
|---|---|---|---|
| Media: | Air | Port Size: | 2-1/2'' 2.5'' Inch |
| Structure: | Diaphragm | Body Material: | Aluminum Alloy |
| Diaphragm Material: | NBR(Common), FKM(Available) | Number Of Diaphragm: | 2 |
| Pressure: | 0.1 To 0.8MPa | Temperature: | -25 To +80℃ |
| High Light: | CA62MM Diaphragm Valve,2.5'' Full Immersion Diaphragm Valve,CA62MM Manifold Flat Mount Valve |
||
CA62MM 2.5'' 2-1/2'' Inch In Line Full Immersion Dust Collector Diaphragm Valve
Typical Applicatoins of Dust Collector Valve:
1. Coal fired boiler dust collectors for power station applications.
2. Process and kiln collectors in cement plants.
3. Long filter or pleated filterbag technology, ideal for high pressure pulsing of 8m and larger filter bags. Equally suitable for high cloth areas of pleated filter bags.
4. Low pressure pulsing applications. The 25% increase in flow capacity will allow lower cleaning system tank pressures than previously achieved in like for like applications.
Technical Data of Goyen Pulse Jet Valve:
|
Model No
|
CA25MM
|
CA40MM
|
CA50MM
|
CA62MM
|
CA76MM
|
CA102MM
|
||
|
Nominal Size
|
25
|
40
|
50
|
62
|
76
|
102
|
||
|
Port Size
|
mm
|
25
|
40
|
50
|
62
|
76
|
102
|
|
|
inch
|
1''
|
1 1/2''
|
2''
|
2 1/2''
|
3''
|
3 1/2''
|
4''
|
|
|
Pressure Range
|
0.3 to 0.8MPa
|
|||||||
|
Temp. Range
|
Nitrile seals
|
-40 to 82℃
|
||||||
|
Viton seals
|
-29 to 232℃
|
|||||||
Main Dimension:
CA RCA Series Pulse Jet Valve For Dust Collector System:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
