1'' Pulse Valve Membrane For BFEC DMF-Z-25 DMF-ZM-25 Repair Kit

1'' Pulse Valve Membrane For BFEC DMF-Z-25 DMF-ZM-25 Repair Kit

  • 1'' Pulse Valve Membrane For BFEC DMF-Z-25 DMF-ZM-25 Repair Kit
1'' Pulse Valve Membrane For BFEC DMF-Z-25 DMF-ZM-25 Repair Kit
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: D25
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Plastic Bags, Cartons, Pallet
Delivery Time: 4-7 Days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Product Name: Pulse Valve Diaphragm Diaphragm Material: NBR
1 Set: 1x Main Diaphragm, 1x Spring Suitable Valve Port Size: 1''
Suitable Valves: DMF-Z-25, DMF-ZM-25 Packaging: Individual Plastic Bag Sealed
High Light:

Pulse Valve Membrane

,

BFEC Membrane

,

SBFEC Membrane

1'' Pulse Valve Membrane For BFEC DMF-Z-25 DMF-ZM-25 Repair Kit



The below diaphragm is used to repair 1 inch BFEC DMF-Z-25, DMF-ZM-25 pulse jet valve. The complete 1 set including 1 pc main diaphragm, 1 pc spring.



The below diaphragm is used to repair 2'' BFEC DMF-Z-50S, DMF-Y-50S pulse jet valve. The complete 1 set including 1 pc main diaphragm, 1pc secodary diaphragm, 2 pcs springs.



The pulse jet valve diaphragm into before and after two of the gas chamber, when switching compressed air, compressed air through the orifice of the gas chamber after entering, and at the time of the gas chamber pressure after the valve diaphragm components will close to losing exports, pulse jet valve is in "off" status.



Pulse jet control instrument signal that the pulse jet valve bit back, after the gas chamber put stomatal open, and the gas chamber pressure loss after quickly, diaphragm components moved, compressed air through the valve lose export injection, pulse jet valve in the "open" status.



Ordering Code No of BFEC Pulse Valve Diaphragm:

Ordering Code
Fitted Valve Code
Port Size
DTY
All Double Diaphragm Pulse Valve
Secondary Diaphragm
D20A
DMF-Z-20, DMF-ZM-20
3/4''
D25
DMF-Z-25, DMF-ZM-25, DMF-ZF-25,
DMF-Y-25, DMF-T-20
3/4'' & 1''
D40
DMF-Z-40S, DMF-Y-40S, DMF-ZF-40S,
DMF-ZM-40S, DMF-T-25S
1'' & 1-1/2''
D50
DMF-Z-50S, DMF-Y-50S, DMF-T-50S
2''
D62
DMF-Z-62S, DMF-Y-62S
2-1/2''
D76
DMF-Z-76S, DMF-Y-76S
3''
D102
DMF-Z-102S DMF-Y-102S
4''
D102A
DMF-Y-102SA
4''
DZL-20B
DMF-ZL-B
3/4''


Dimension of 1'' Pulse Valve Diaphragm Repair Kit:

1'' Pulse Valve Membrane For BFEC DMF-Z-25 DMF-ZM-25 Repair Kit 0



Video of 1'' Pulse Valve Diaphragm Repair Kit:



Brando Production of Pulse Valve Diaphragms:

1271526 Diaphragm Repair Kit For Norgren 3'' 8296900 Pulse Valve 10



More BFEC Pulse Valve For You to Choose:

1'' Pulse Valve Membrane For BFEC DMF-Z-25 DMF-ZM-25 Repair Kit 21'' Pulse Valve Membrane For BFEC DMF-Z-25 DMF-ZM-25 Repair Kit 31'' Pulse Valve Membrane For BFEC DMF-Z-25 DMF-ZM-25 Repair Kit 4

              Right Angle Type                      Quick Mount Type                         Submerged Type

1'' Pulse Valve Membrane For BFEC DMF-Z-25 DMF-ZM-25 Repair Kit 5 1'' Pulse Valve Membrane For BFEC DMF-Z-25 DMF-ZM-25 Repair Kit 6 1'' Pulse Valve Membrane For BFEC DMF-Z-25 DMF-ZM-25 Repair Kit 7

                Solenoid Coil                            Armature Assembly                       Pulse Controller
