| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | CA76T |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Type: | Right Angle Diaphragm Valve | Power: | Solenoid |
|---|---|---|---|
| Media: | Air | Port Size: | 3''Inch |
| Structure: | Diaphragm | Body Material: | Aluminum Alloy |
| Diaphragm Material: | NBR(Common), FKM(Available) | Number Of Diaphragm: | 2 |
| Pressure: | 0.1 To 0.8MPa | Temperature: | -25 To +80℃ |
| High Light: | CA76T010-300 Pulse Jet Valve,CA76T010-305 Pulse Jet Valve,Goyen Type Baghouse System Valve |
||
CA76T CA76T010-300 CA76T010-305 3'' Inch Baghouse System Pulse Jet Valve
Right Angle Pulse Valve Working Principle:
When the pulse solenoid valve is opened, the air in the air bag enters the blow pipe through the pulse valve, and is sprayed to the filter bag, so that the dust bag is rapidly expanded, and the dust on the dust bag is shaken off, the dust bag is clean and the air permeability is improved, and the dust remover is cleaned. continue working. For the case that the valve opening is only closed for a short time, the normally open pulse
solenoid valve should be used. When used in short-term work and large batch sizes, special orders can be made to reduce power consumption.
Controlled by the output signal of the pulse blowing controller, the filter bags are cleaned one by one, the large particles fall directly into the ash bucket, and the small particles adhere to the filter bag. When the dust on the filter bag is too much, the gas permeability is not good. The negative pressure of the precipitator is too large, the differential pressure controller gives a signal to the PLC, then the PLC automatically starts the pulse valve, the pulse valve will automatically open, and the filtered static air enters the upper tank to discharge, so that the resistance of the precipitator remains at the set Within the scope to ensure the processing capacity and dust collection efficiency of the dust collector.
Technical Data of Goyen Pulse Jet Valve:
|
Model No
|
CA15T
|
CA20T
|
CA25T
|
CA35T
|
CA45T
|
CA50T
|
CA62T
|
CA76T
|
|
Nonimal size
|
φ15
|
φ20
|
φ25
|
φ35
|
φ45
|
φ50
|
φ62
|
φ76
|
|
Port Size
|
G1/2''
|
G3/4''
|
G1''
|
G1 1/4''
|
G1 1/2''
|
G2''
|
G2 1/2''
|
G3''
|
|
Working pressure
|
0.3-0.8MPa
|
|||||||
|
Temp. range
|
-5℃ - 55℃
|
|||||||
|
Relative humidity
|
≤85%
|
|||||||
|
Working
medium
|
Compressed clean air
|
|||||||
|
Service life
|
Over 1000000 times
|
|||||||
|
Voltage
|
DC24V, AC24V, AC110V, AC220V
|
|||||||
Main Dimension:
CA RCA Series Pulse Jet Valve For Dust Collector System:
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
