SBFEC Type DMF-Z-62S 2-1/2'' Inch Dust Collector Pulse Jet Valve

SBFEC Type DMF-Z-62S 2-1/2'' Inch Dust Collector Pulse Jet Valve

  • SBFEC Type DMF-Z-62S 2-1/2'' Inch Dust Collector Pulse Jet Valve
SBFEC Type DMF-Z-62S 2-1/2'' Inch Dust Collector Pulse Jet Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: DMF-Z-62S
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Packaging Details: inner boxes,cartons,pallets
Delivery Time: 7 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Type: Right Angle Diaphragm Valve Power: Solenoid
Media: Air Port Size: 2-1/2''Inch
Structure: Diaphragm Body Material: Aluminum Alloy
Diaphragm Material: NBR(Common), FKM(Available) Number Of Diaphragm: 2
Pressure: 0.1 To 0.8MPa Temperature: -25 To +80℃
High Light:

DMF-Z-62S Pulse Jet Valve

,

2-1/2'' Inch Pulse Jet Valve

,

BFEC DMF-Z-62S Right Angle

SBFEC Type DMF-Z-62S 2-1/2'' Inch Dust Collector Pulse Jet Valve



Installation

1. Prepare supply and blowtube pipes to suit valve specification. Avoid installing valves underneath the tank.
2. Ensure tank and pipes are free from dirt, rust or other particulate.
3. Ensure supply air is clean and dry.
4. Mount valves to inlet pipes and blowtube to valves, ensuring no excess thread sealant can enter the valve itself.
5. Make electrical connections to solenoid
6. Apply moderate pressure to system and check for installation leaks.
7. Fully pressurise system.
8. Test fire and listen for proper actuation and crisp pulse noise.



Technical Data of SBFEC Type DMF Series Right Angle Pulse Jet Valve:

Model
Nominal diametrer
Number of diaphragms
Inlet
Outlet
Weight (kg)
mm
inch
DMF-Z-20
Φ20
3/4''
1
G3/4''
G3/4''
0.65
DMF-Z-25
Φ25
1'''
1
G1''
G1''
0.8
DMF-Z-40S
Φ40
1 1/2''
2
G1 1/2''
G1 1/2''
1.4
DMF-Z-50S
Φ50
2''
2
G 2''
G2
2.4
DMF-Z-62S
Φ62
2 1/2''
2
G2 1/2''
G2 1/2''
3.5
DMF-Z-76S
Φ76
3''
2
G3''
G3''
4.3
DMF-Z-90S
Φ90
3 1/2''
2
G3 1/2''
G3 1/2''
5.75
DMF-Z-102S
Φ102
4''
2
G4''
G4''
7.3
DMF-ZL-B
Φ20
3/4''
1
G3/4''
Φ27
0.75


Main Dimension:

SBFEC Type DMF-Z-62S 2-1/2'' Inch Dust Collector Pulse Jet Valve 0



BFEC DMF Series Pulse Jet Valve For Dust Collector System:



Thread Valve
3/4''
1''
1.5''
2''
2.5''
3''
4''
DMF-Z-20
DMF-Z-25
DMF-Z-40S
DMF-Z-50S
DMF-Z-62S
DMF-Z-76S
DMF-Z-102S
Quick Mount Valve
3/4''
Inlet φ27
1''
1.5''
DMF-ZM-20
DMF-ZL-B
DMF-ZM-25
DMF-ZM-40S
Flange Valve
1''
1.5''
DMF-ZF-25
DMF-ZF-40S
Embedded Valve
1''
1.5''
Outlet φ62mm
Outlet φ75
Outlet φ89
Outlet φ114
Outlet φ102
DMF-Y-25
DMF-Y-40S
DMF-Y-50S
DMF-Y-62S
DMF-Y-76S
DMF-Y-102S
DMF-Y-102SA
