2 Inch Dust Collector Solenoid Valve SCG353A050 ASCO Type

2 Inch Dust Collector Solenoid Valve SCG353A050 ASCO Type

  • 2 Inch Dust Collector Solenoid Valve SCG353A050 ASCO Type
2 Inch Dust Collector Solenoid Valve SCG353A050 ASCO Type
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: SCG353A050
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-7 days
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: Pulse Jet Valve Port Size: 2 Inch
Remote Or Integral: Integral Pilot Body Material: Aluminum
Diaphragm Material: NBR Pressure Range: 0.3 To 0.8MPa
Valve Type: Right Angle Voltages: 220VAC, 24VDC
High Light:

Dust Collector Solenoid Valve

,

ASCO Solenoid Valve

,

ASCO SCG353A050

2 Inch Dust Collector Solenoid Valve SCG353A050 ASCO Type



353 Series ASCO Type Pulse Jet Valve:



1. Threaded Pulse Jet Valve: SCG353A043, SCG353A044, SCG353A047, SCG353A050, SCG353A051.



2. Remote Pilot Pulse Jet Valve: G353A041, G353A042, G353A045.



3. Immersion Pulse Jet Valve: SCXE353.060.



Pulse jet valve, also called diaphragm valve acts as a “switch” for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse-jet control device.Pulse jet valves are used in filtering systems of dust collectors, gas turbines, and desulfurization equipment. They are commonly used to clean filters such as cartridge filters, envelope filters, ceramic filters, and sintered metal fiber filters.



Technical Data of 353 Series Pulse Jet Valves:

Model No
SCG353A043
SCG353A044
SCG353A047
SCG353A050
SCG353A051
Port Size
G3/4''
G1''
G1-1/2''
G2''
G2-1/2''
Nominal Size
φ20mm
φ25mm
φ40mm
φ50mm
φ62mm
Working Pressure
0.3 to 0.8MPa
Environment Temperature
-5 to +55℃
Relative Humidity
≤85%
Operating Medium
Dry clean compressed air
Voltages
220VAC, 24VDC



Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.



Dimension of SCG353A050 Pulse Jet Valve:

2 Inch Dust Collector Solenoid Valve SCG353A050 ASCO Type 0



Video of SCG353A050 Pulse Jet Valve:



More ASCO Type Pulse Valve For You to Choose:

2 Inch Dust Collector Solenoid Valve SCG353A050 ASCO Type 12 Inch Dust Collector Solenoid Valve SCG353A050 ASCO Type 22 Inch Dust Collector Solenoid Valve SCG353A050 ASCO Type 3

           Right Angle Type                        Remote Pilot Type                       Immersion Type

2 Inch Dust Collector Solenoid Valve SCG353A050 ASCO Type 42 Inch Dust Collector Solenoid Valve SCG353A050 ASCO Type 52 Inch Dust Collector Solenoid Valve SCG353A050 ASCO Type 62 Inch Dust Collector Solenoid Valve SCG353A050 ASCO Type 7

            Diaphragm                     Solenoid Coil                Armature Assembly            Pulse Controller
