| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | SCG353A047 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-7 days |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 100000 pcs per month |
| Product Name: | Pulse Jet Valve | Port Size: | 1.5 Inch |
|---|---|---|---|
| Remote Or Integral: | Integral Pilot | Body Material: | Aluminum |
| Diaphragm Material: | NBR | Pressure Range: | 0.3 To 0.8MPa |
| Valve Type: | Right Angle | Voltages: | 220VAC, 24VDC |
| High Light: | Baghouse Pulse Valve,SCG353A047 ASCO Pulse Valve,ASCO Numatics SCG353A047 |
||
1 1/2 Inch Baghouse Diaphragm Pulse Valve SCG353A047 ASCO Type
Pulse Jet Valve, also called diaphragm valve acts as a "switch" for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse-jet control device. This system cleans the filter bags cluster by cluster with high-pressure blowing to keep the pressure resistance of the baghouse within a pre-set range, and thus ensure the processing capability and the dust-collecting efficiency of the baghouse.
List of 353 Series ASCO Type Pulse Jet Valve:
1. Threaded Pulse Jet Valve: SCG353A043, SCG353A044, SCG353A047, SCG353A050, SCG353A051.
2. Remote Pilot Pulse Jet Valve: G353A041, G353A042, G353A045.
3. Immersion Pulse Jet Valve: SCXE353.060.
Technical Data of 353 Series Pulse Jet Valves:
Dimension of SCG353A047 Pulse Jet Valve:
Video of SCG353A047 Pulse Jet Valve:
More ASCO Type Pulse Valve For You to Choose:
Right Angle Type Remote Pilot Type Immersion Type
Diaphragm Solenoid Coil Armature Assembly Pulse Controller
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
Contact Person: Brandon
Tel: +8613454729544
