| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | SCG353A043 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Inner Box, Carton, Pallet |
| Delivery Time: | 4-7 days |
| Payment Terms: | L/C, T/T, Western Union, Paypal |
| Supply Ability: | 100000 pcs per month |
| Product Name: | Pulse Jet Valve | Port Size: | 3/4 Inch |
|---|---|---|---|
| Remote Or Integral: | Integral Pilot | Body Material: | Aluminum |
| Diaphragm Material: | NBR, TPE | Pressure Range: | 0.3MPa To 0.8MPa |
| Valve Type: | Right Angle | Voltages: | 220V AC, 24V DC |
| High Light: | Bag Filter Pulse Valve,ASCO Pulse Valve,SCG353A043 ASCO |
||
3/4 Inch Bag Filter Diaphragm Pulse Valve SCG353A043 ASCO Type
353 Series is a high-performance pulse jet valve with threaded ports. Available with integral pilot or as a remotely piloted valve. Outlet at 90°. Pulse jet valve, also called diaphragm valve acts as a “switch” for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse-jet control device.Pulse jet valves are used in filtering systems of dust collectors, gas turbines, and desulfurization equipment. They are commonly used to clean filters such as cartridge filters, envelope filters, ceramic filters, and sintered metal fiber filters.
Technical Data of 353 Series Pulse Jet Valves:
Dimension of SCG353A043 Pulse Jet Valve:
Video of SCG353A043 Pulse Jet Valve:
More ASCO Type Pulse Valve For You to Choose:
Right Angle Type Remote Pilot Type Immersion Type
Diaphragm Solenoid Coil Armature Assembly Pulse Controller
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
