Name: BFEC 2-1/2'' DMF-Y-62S Embedded Bag Filter Diaphragm Valve
Brand: Brando
SKU: DMF-Y-62S
Rating: 4.8 (183 reviews)

Home Products Pulse Jet Valve

BFEC 2-1/2'' DMF-Y-62S Embedded Bag Filter Diaphragm Valve

Product Details:

Place of Origin:	China
Brand Name:	Brando
Certification:	CE
Model Number:	DMF-Y-62S

Payment & Shipping Terms:

Minimum Order Quantity:	1 pc
Packaging Details:	inner boxes,cartons,pallets
Delivery Time:	7 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	100000 pcs per month

Contact Now

Detailed Product Description

Type:	Full Immersion Diaphragm Valve	Power:	Solenoid
Media:	Air	Port Size:	2-1/2''Inch
Structure:	Diaphragm	Body Material:	Aluminum Alloy
Diaphragm Material:	NBR(Common), FKM(Available)	Number Of Diaphragm:	2
Pressure:	0.1 To 0.8MPa	Temperature:	-25 To +80℃
High Light:	Embedded Pulse jet Valve , Bag Filter Pulse Jet Valve , SBFEC TyPE Embedded DMF-Y-62S

BFEC 2-1/2'' DMF-Y-62S Embedded Bag Filter Diaphragm Valve

Main Type of SBFEC Type Baghouse Pulse Jet Valve:

1.Right Angle Valve

This kind of pulse valve with an included angle of 90° between inlet and outlet. It simplifies the connection between gas bag and blowing tube of a dust collector. It can provide stronger airflow and meet dust removing requirements. Like DMF-Z Series Pulse Valve.

2.Submerged Valve

This kind of pulse valve is installed directly on a secondary gas bag and achieves better circulation quality. The valve has less pressure loss, and is applicable to the operations with lower gas pressure.Like DMF-Y Series Pulse Valve.

3.Dresser Nut Valve

This kind of pulse valve is similar to the z-series valves, suitable for connection between gas bag and blowing tube of a dust collector. It has fixed nuts for installation purposes at the inlet and outlet end, for easier installation and application. Like DMF-ZM Series Pulse Valve.

4.Through Valve

This kind of pulse valve with an included angle of 180° between the inlet and outlet (central line of both inlet and outlet are the same straight line). Also, the inlet is connected to a gas storage tank, while its outlet is connected to a blowing tube. Like DMF-T Series Pulse Valve.

All Kinds of pulse jet valve in stock. Welcome inquiry.

Technical Data of SBFEC Type DMF Series Submerged Pulse Jet Valve:

Model number	DMF-Y-25	DMF-Y-40S	DMF-Y-50S	DMF-Y-62S	DMF-Y-76S	DMF-Y-102S
Port sizes	G1''	G1 1/2''	G2''	G2 1/2''	G3''	G4''
Membrane sizes (φ66 smaller)	φ96	φ112	φ160	φ188	φ202	φ255
CV values	30.53	53.47	71.47	150.85	186.66	313.09
Blowing area (m2)	8-10	12-16	18-28	27-38	37-65	70-90
Weight (kg)	0.75	1.2	2.35	3.2	4.05	5.65
Environment Temperature	-25℃ to +80℃
Relative Humidity	≤85%
Working Medium	Clean Air
Protection Class	IP65
Service Life	Over one million times
Voltage	DC24V, AC24V, AC110V, AC220V

Main Dimension:

BFEC 2-1/2'' DMF-Y-62S Embedded Bag Filter Diaphragm Valve 0

BFEC DMF Series Pulse Jet Valve For Dust Collector System:

Thread Valve	3/4''	1''	1.5''	2''	2.5''	3''	4''
Thread Valve	DMF-Z-20	DMF-Z-25	DMF-Z-40S	DMF-Z-50S	DMF-Z-62S	DMF-Z-76S	DMF-Z-102S
Quick Mount Valve	3/4''	Inlet φ27	1''		1.5''
Quick Mount Valve	DMF-ZM-20	DMF-ZL-B	DMF-ZM-25		DMF-ZM-40S
Flange Valve	1''			1.5''
Flange Valve	DMF-ZF-25			DMF-ZF-40S
Embedded Valve	1''	1.5''	Outlet φ62mm	Outlet φ75	Outlet φ89	Outlet φ114	Outlet φ102
Embedded Valve	DMF-Y-25	DMF-Y-40S	DMF-Y-50S	DMF-Y-62S	DMF-Y-76S	DMF-Y-102S	DMF-Y-102SA
