1.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector

1.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector

  • 1.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector
  • 1.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector
  • 1.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector
1.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: SCG353A047
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-7 days
Payment Terms: L/C, T/T, Western Union, Paypal
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: Pulse Jet Valve Port Size: 1.5''
Remote Or Integral: Integral Pilot Body Material: Aluminum Diecast
Diaphragm Material: NBR (TPE On Request) Pressure Range: 0.3 To 0.8MPa
Valve Type: Right Angle Voltages: 220V AC, 24V DC
High Light:

ASCO Pulse Jet Valve

,

Dust Collector Pulse Jet Valve

,

ASCO SCG353A047

1.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector​



353 Series ASCO Type Pulse Jet Valve:



1. Threaded Pulse Jet Valve: SCG353A043, SCG353A044, SCG353A047, SCG353A050, SCG353A051.



2. Remote Pilot Pulse Jet Valve: G353A041, G353A042, G353A045.



3. Immersion Pulse Jet Valve: SCXE353.060.



Pulse jet valve, also called diaphragm valve acts as a “switch” for compressed air in the dust clean blowing system for pulse bag filters. It is controlled by the electric signals from the pulse-jet control device.Pulse jet valves are used in filtering systems of dust collectors, gas turbines, and desulfurization equipment. They are commonly used to clean filters such as cartridge filters, envelope filters, ceramic filters, and sintered metal fiber filters.



Technical Data of 353 Series Pulse Jet Valves:

Model No
SCG353A043
SCG353A044
SCG353A047
SCG353A050
SCG353A051
Port Size
G3/4''
G1''
G1-1/2''
G2''
G2-1/2''
Nominal Size
φ20mm
φ25mm
φ40mm
φ50mm
φ62mm
Working Pressure
0.3 to 0.8MPa
Environment Temperature
-5 to +55℃
Relative Humidity
≤85%
Operating Medium
Dry clean compressed air
Voltages
220VAC, 24VDC



Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.



Dimension of SCG353A047 Pulse Jet Valve:

1.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector 0



Video of SCG353A047 Pulse Jet Valve:





More ASCO Type Pulse Valve For You to Choose:

1.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector 11.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector 21.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector 3

           Right Angle Type                        Remote Pilot Type                       Immersion Type

1.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector 41.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector 51.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector 61.5" SCG353A047 ASCO Type Pulse Jet Valve For Dust Collector 7

            Diaphragm                     Solenoid Coil                Armature Assembly            Pulse Controller
