DMF-ZM-25 BFEC Quick Mount Pulse Valve For Dust Collector

DMF-ZM-25 BFEC Quick Mount Pulse Valve For Dust Collector

  • DMF-ZM-25 BFEC Quick Mount Pulse Valve For Dust Collector
DMF-ZM-25 BFEC Quick Mount Pulse Valve For Dust Collector
Product Details:
Place of Origin: CHINA
Brand Name: BRANDO
Certification: CE
Model Number: DMF-ZM-25
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box,Carton,Pallet
Delivery Time: 4-7 days
Payment Terms: T/T, Western Union, L/C, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: BFEC Pulse Jet Valve Valve Type: Quick Mount
Port Size: 1'' Coil Voltage: 24VDC, 220VAC
Diaphragm Material: NBR No Of Diaphragm: 1
High Light:

Quick Mount Pulse Valve

,

Dust Collector Pulse Valve

,

DMF-ZM-25 Pulse Valve

DMF-ZM-25 BFEC Quick Mount Pulse Valve For Dust Collector



ZM series of pulse jet valves includes models with dresser nut ports from 3/4'' to 1-1/2''. These valves are particular used for reverse pulse-jet filter cleaning of filter bags, cartridges, envelope filters, ceramic filters and sintered metal fibre filters.



They have an inlet port at 90° to the outlet port.



The pulse jet valves differ in types with an integrated pilot valve or with external pneumatic control.



The special design ensures extremely fast opening, high flow and easy installation.



Optionally, we also offer versions with ATEX certified pilot valves.



A well thought-out structure and a fast delivery time for spare parts such as diaphragms, springs and coils enable simple maintenances.


Technical Data of Quick Mount Pulse Jet Valves:

Model
DMF-ZM-20
DMF-ZM-25
DMF-ZM-40S
Nominal Size
20
25
40
Port size
mm
20
25
40
in
3/4
1
1 1/2
Blowing Area (m2)
3.5~6
8~10
12~16
Number of Diaphragms
1
1
2
Flow
Kv
17.55
26.16
45.82
Cv
20.48
50.53
53.47
Pressure (Psi)
0.1Mpa to 0.8Mpa
Temperature (℃)
-25℃ to +80℃
Voltage
220VAC, 24VDC


Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.



Dimension of DMF-ZM-25 BFEC Pulse Jet Valve:

DMF-ZM-25 BFEC Quick Mount Pulse Valve For Dust Collector 0



Video of BFEC DMF-ZM-25 Pulse Jet Valve:


More BFEC Pulse Valve For You to Choose:

DMF-ZM-25 BFEC Quick Mount Pulse Valve For Dust Collector 1DMF-ZM-25 BFEC Quick Mount Pulse Valve For Dust Collector 2DMF-ZM-25 BFEC Quick Mount Pulse Valve For Dust Collector 3

           Right Angle Type                         Quick Mount Type                         Submerged Type

DMF-ZM-25 BFEC Quick Mount Pulse Valve For Dust Collector 4DMF-ZM-25 BFEC Quick Mount Pulse Valve For Dust Collector 5 DMF-ZM-25 BFEC Quick Mount Pulse Valve For Dust Collector 6 DMF-ZM-25 BFEC Quick Mount Pulse Valve For Dust Collector 7

            Diaphragm                     Solenoid Coil                  Armature Assembly            Pulse Controller
