2 1/2'' BFEC DMF-Z-62S Dust Collector Pulse Valve 24V 220V

2 1/2'' BFEC DMF-Z-62S Dust Collector Pulse Valve 24V 220V

  • 2 1/2'' BFEC DMF-Z-62S Dust Collector Pulse Valve 24V 220V
2 1/2'' BFEC DMF-Z-62S Dust Collector Pulse Valve 24V 220V
Product Details:
Place of Origin: CHINA
Brand Name: BRANDO
Certification: CE
Model Number: DMF-Z-62S
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box,Carton,Pallet
Delivery Time: 4-7 days
Payment Terms: T/T, Western Union, L/C, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: BFEC Pulse Jet Valve Valve Type: Right Angle (Threaded)
Port Size: 2.5'' Coil Voltage: 24VDC, 220VAC
Diaphragm Material: NBR No Of Diaphragm: 2
High Light:

Dust Collector Pulse Valve

,

BFEC Pulse Valve

,

DMF-Z-62S Pulse Valve

2 1/2'' BFEC DMF-Z-62S Dust Collector Pulse Valve 24V 220V



Pulse jet valve (also called diaphragm valve) is the "switch" for compressed air in the dust clean blowing system of the pulse bag filter. Controlled by the output signals of the pulse control device, it makes dust clean to the filter bags cell by cell to keep the resistance of the bag house within the sec range and thus guarantee the processing functions and the dust collecting efficiency of the bag house dust collector. Our pulse jet valves are designed specifically for dust applications with high flow, long life and fast on / off switching characteristics, to ensure economic and reliable work.


Technical Data of  Z series Right Angle Pulse Jet Valves:

Model
Nominal diametrer
Number of diaphragms
Inlet
Outlet
Weight (kg)
mm
inch
DMF-Z-20
Φ20
3/4''
1
3/4''
3/4''
0.65
DMF-Z-25
Φ25
1'''
1
1''
1''
0.8
DMF-Z-40S
Φ40
1 1/2''
2
1 1/2''
1 1/2''
1.4
DMF-Z-50S
Φ50
2''
2
2''
2
2.4
DMF-Z-62S
Φ62
2 1/2''
2
2 1/2''
2 1/2''
3.5
DMF-Z-76S
Φ76
3''
2
3''
3''
4.3
DMF-Z-90S
Φ90
3 1/2''
2
3 1/2''
3 1/2''
5.75
DMF-Z-102S
Φ102
4''
2
4''
4''
7.3
DMF-20L-B
Φ20
3/4''
1
3/4''
Φ27
0.75



Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.



Dimension of DMF-Z-62S BFEC Pulse Jet Valve:

2 1/2'' BFEC DMF-Z-62S Dust Collector Pulse Valve 24V 220V 0



Video of DMF-Z-62S BFEC Pulse Jet Valve:




More BFEC Pulse Valve For You to Choose:

2 1/2'' BFEC DMF-Z-62S Dust Collector Pulse Valve 24V 220V 12 1/2'' BFEC DMF-Z-62S Dust Collector Pulse Valve 24V 220V 22 1/2'' BFEC DMF-Z-62S Dust Collector Pulse Valve 24V 220V 3

           Right Angle Type                         Quick Mount Type                         Submerged Type

2 1/2'' BFEC DMF-Z-62S Dust Collector Pulse Valve 24V 220V 42 1/2'' BFEC DMF-Z-62S Dust Collector Pulse Valve 24V 220V 5 2 1/2'' BFEC DMF-Z-62S Dust Collector Pulse Valve 24V 220V 6 2 1/2'' BFEC DMF-Z-62S Dust Collector Pulse Valve 24V 220V 7

            Diaphragm                     Solenoid Coil                  Armature Assembly            Pulse Controller
