1.5 Inch DMF-Z-40S BFEC Diaphragm Pulse Jet Valve For Bag Filter

1.5 Inch DMF-Z-40S BFEC Diaphragm Pulse Jet Valve For Bag Filter

    • 1.5 Inch DMF-Z-40S BFEC Diaphragm Pulse Jet Valve For Bag Filter
  • 1.5 Inch DMF-Z-40S BFEC Diaphragm Pulse Jet Valve For Bag Filter

    Product Details:

    Place of Origin: CHINA
    Brand Name: BRANDO
    Certification: CE
    Model Number: DMF-Z-40S

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: negotiation
    Packaging Details: Inner Box,Carton,Pallet
    Delivery Time: 4-7 days
    Payment Terms: T/T, Western Union, L/C, MoneyGram
    Supply Ability: 100000 pcs per month
    Contact Now
    Detailed Product Description
    Product Name: BFEC Pulse Jet Valve Valve Type: Right Angle (Threaded)
    Port Size: 1.5'' Coil Voltage: 24VDC, 220VAC
    Diaphragm Material: NBR No Of Diaphragm: 2
    High Light:

    Pulse Jet Valve For Bag Filter

    ,

    Diaphragm Pulse Jet Valve

    ,

    BFEC Pulse Jet Valve

    1.5 Inch DMF-Z-40S BFEC Diaphragm Pulse Jet Valve For Bag Filter



    Pulse Jet Valve Operation:



    Our pulse jet valves are operated by integral solenoid pilot operator. When the valve is energised, the trapped air above pulse valve diaphgram is quickly exhausted causing fast opening of main diaphragm valve. When the pilot operated valve is de - energised , air escapes through bleed hole of main pulse valve to balance the diaphragm pressure and instantly closes the valve.



    Duty Cycle : The relative duty time cycle for ac voltage is 20% and for DC voltage is 10 % .This implies energised time is maximum 1/5th of de-energised time for AC and 1/10th for DC voltage.



    Installation : Mounting in any position will not affect pulse valve operation. However good engineering practice is to avoid scale and condensed water entering valve body for trouble free performance.


    Technical Data of  Z series Right Angle Pulse Jet Valves:

    Model
    Nominal diametrer
    Number of diaphragms
    Inlet
    Outlet
    Weight (kg)
    mm
    inch
    DMF-Z-20
    Φ20
    3/4''
    1
    3/4''
    3/4''
    0.65
    DMF-Z-25
    Φ25
    1'''
    1
    1''
    1''
    0.8
    DMF-Z-40S
    Φ40
    1 1/2''
    2
    1 1/2''
    1 1/2''
    1.4
    DMF-Z-50S
    Φ50
    2''
    2
    2''
    2
    2.4
    DMF-Z-62S
    Φ62
    2 1/2''
    2
    2 1/2''
    2 1/2''
    3.5
    DMF-Z-76S
    Φ76
    3''
    2
    3''
    3''
    4.3
    DMF-Z-90S
    Φ90
    3 1/2''
    2
    3 1/2''
    3 1/2''
    5.75
    DMF-Z-102S
    Φ102
    4''
    2
    4''
    4''
    7.3
    DMF-20L-B
    Φ20
    3/4''
    1
    3/4''
    Φ27
    0.75



    Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.



    Dimension of DMF-Z-40S BFEC Pulse Jet Valve:

    1.5 Inch DMF-Z-40S BFEC Diaphragm Pulse Jet Valve For Bag Filter 0



    Video of BFEC DMF-Z-40S Pulse Jet Valve:


    More BFEC Pulse Valve For You to Choose:

    1.5 Inch DMF-Z-40S BFEC Diaphragm Pulse Jet Valve For Bag Filter 11.5 Inch DMF-Z-40S BFEC Diaphragm Pulse Jet Valve For Bag Filter 21.5 Inch DMF-Z-40S BFEC Diaphragm Pulse Jet Valve For Bag Filter 3

               Right Angle Type                         Quick Mount Type                         Submerged Type

    1.5 Inch DMF-Z-40S BFEC Diaphragm Pulse Jet Valve For Bag Filter 41.5 Inch DMF-Z-40S BFEC Diaphragm Pulse Jet Valve For Bag Filter 5 1.5 Inch DMF-Z-40S BFEC Diaphragm Pulse Jet Valve For Bag Filter 6 1.5 Inch DMF-Z-40S BFEC Diaphragm Pulse Jet Valve For Bag Filter 7

                Diaphragm                     Solenoid Coil                  Armature Assembly            Pulse Controller
