| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4A210-06 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Packaging Details: | inner boxes,cartons,pallets |
| Delivery Time: | 7 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 100000 pcs per month |
| Port Size: | 1/8 Inch | Valve Type: | Single Solenoid 5 Port 2 Position |
|---|---|---|---|
| Voltage: | 220VAC 110VAC 24VDC 12VDC | Working Pressure: | 0.15 To 0.8MPa(21-114psi) |
| Temperature: | -20 To +70℃ | Max. Frequency: | 5 Cycle/sec |
| Body Material: | Aluminum Alloy | Fluid: | Air (to Be Filtered By 40 μm Filter Element) |
| Application: | Automation | CV: | 0.78 |
| High Light: | 4V210-06 Pneumatic Solenoid Valve,4A200 Series Pneumatic Solenoid Valve,4A210-08 Air Pilot Valve |
||
4A210-06 1/8'' 5/2 Way Single Air Control Valve
Technical Data:
| Model |
4A210-06 4A220-06 |
4A230C-06 4A230E-06 4A230P-06 |
4A210-08 4A220-08 |
4A230C-08 4A230E-08 4A230P-08 |
| Fluid | Air(to be filtered by 40 μ m filter element) | |||
| Acting | Exterior control | |||
| Port Size | In=Out=Exhaust=1/8'' | In=Out=1/4'', Exhaust=1/8'' | ||
| CV | 0.78 | 0.67 | 0.89 | 0.67 |
| Valve Type | 5 Port 2 Position | 5 Port 3 Position | 5 Port 2 Position | 5 Port 3 Position |
| Operating Pressure | 21~114psi(0.15~0.8MPa) | |||
| Temperature | -20~70℃ | |||
| Material of body | Alumium Alloy | |||
| Max. frequency | 5 cycle/sec | 3 cycle/sec | 5 cycle/sec | 3 cycle/sec |
Dimension Diagram:
Brando Supply:
1.Solenoid Valve:
Pulse Jet Valve: Goyen Type Pulse Jet Valve, SBFEC Type Pulse Jet Valve, ASCO Type Pulse Jet Valve , Turbo Type Pulse Jet Valve.
Direct Acting Solenoid Valve:Brass Solenoid Valve, Stainless Steel Solenoid Valve, Plastic Solenoid Valve and etc.
Refrigeration Solenoid Valve:Castel Type Solenoid Valve, Danfoss Type Solenoid Valve.
2.Repair Kit:Solenoid Coil, Solenoid Armature/Stem, Diaphragm Repair Kit and etc.
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
