BFEC DMF-Y-102S 4'' Submerged Dust Collector Pulse Solenoid Valve

BFEC DMF-Y-102S 4'' Submerged Dust Collector Pulse Solenoid Valve

  • BFEC DMF-Y-102S 4'' Submerged Dust Collector Pulse Solenoid Valve
BFEC DMF-Y-102S 4'' Submerged Dust Collector Pulse Solenoid Valve
Product Details:
Place of Origin: CHINA
Brand Name: BRANDO
Certification: CE
Model Number: DMF-Y-102S
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box,Carton,Pallet
Delivery Time: 4-7 days
Payment Terms: T/T, Western Union, L/C, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: BFEC Pulse Jet Valve Valve Type: Submerged
Port Size: 4'' Coil Voltage: 24V, 220V
Diaphragm Material: NBR No Of Diaphragm: 2
High Light:

Pulse Solenoid Valve

,

Dust Collector Solenoid Valve

,

Dust Collector Pulse Jet Valve

BFEC DMF-Y-102S 4'' Submerged Dust Collector Pulse Solenoid Valve



Submerged pulse jet valve for pulse jet dust bag filter. This type of pulse valve using submerged in the air bag in the structure, compared with other structure, reducing the channel resistance, reducing the supply pressure blowing spray, which can be applied in low pressure situations, and can reduce energy consumption and extend the membrane life.



Product Structure:



Housing: valve housing and cover are made ​​of die cast aluminum alloy, good appearance, high intensity, to ensure that no air leaks. Pressure flow channel valve design is reasonable, the valve opening and closing and basically located in the air bag, truly a "submerged" by the air bag directly into the air injection tube, which really achieve the low pressure, high volume injection requirements.



Solenoid valve: a large displacement of the diaphragm in a short time can be 0.08 to 0.1 seconds to ensure the opening degree of the valve . Optional imported materials developed synthetic rubber diaphragm when applied to a cold climate. Operating temperature between -40 ℃ to 55 ℃, and ensures the longest working life.



Technical Data of  Y series Submerged Pulse Jet Valves:

Model number
DMF-Y-25
DMF-Y-40S
DMF-Y-50S
DMF-Y-62S
DMF-Y-76S
DMF-Y-102S
Port sizes
1''
1 1/2''
2''
2 1/2''
3''
4''
Membrane sizes
(φ66 smaller)
φ96
φ112
φ160
φ188
φ202
φ255
CV values
30.53
53.47
71.47
150.85
186.66
313.09
Blowing area
(m2)
8-10
12-16
18-28
27-38
37-65
70-90
Environment Temperature
-25℃ to +80℃
Relative Humidity
≤85%
Working Medium
Clean Air
Protection Class
IP65
Voltage
24VDC, 220VAC



Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.



Dimension of DMF-Y-102S BFEC Pulse Jet Valve:

BFEC DMF-Y-102S 4'' Submerged Dust Collector Pulse Solenoid Valve 0



Video of DMF-Y-102S Submerged Pulse Jet Valve:





More BFEC Pulse Valve For You to Choose:

BFEC DMF-Y-102S 4'' Submerged Dust Collector Pulse Solenoid Valve 1BFEC DMF-Y-102S 4'' Submerged Dust Collector Pulse Solenoid Valve 2BFEC DMF-Y-102S 4'' Submerged Dust Collector Pulse Solenoid Valve 3

           Right Angle Type                         Quick Mount Type                         Submerged Type

BFEC DMF-Y-102S 4'' Submerged Dust Collector Pulse Solenoid Valve 4BFEC DMF-Y-102S 4'' Submerged Dust Collector Pulse Solenoid Valve 5 BFEC DMF-Y-102S 4'' Submerged Dust Collector Pulse Solenoid Valve 6 BFEC DMF-Y-102S 4'' Submerged Dust Collector Pulse Solenoid Valve 7

            Diaphragm                     Solenoid Coil                  Armature Assembly            Pulse Controller
