3 Inch CA76MM Goyen Type Submerged Dust Collector Pulse Valve

3 Inch CA76MM Goyen Type Submerged Dust Collector Pulse Valve

3 Inch CA76MM Goyen Type Submerged Dust Collector Pulse Valve
video
3 Inch CA76MM Goyen Type Submerged Dust Collector Pulse Valve
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: CA76MM
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: Pulse Jet Valve Valve Type: Full Immersion
Port Size: 3'' Diaphragm Material: NBR
Working Pressure Range: 0.3 To 0.8 MPa Voltage: 24VDC, 220VAC
High Light:

Dust Collector Pulse Valve

,

3 Inch Pulse Valve

,

Submerged Pulse Valve

3 Inch CA76MM Goyen Type Submerged Dust Collector Pulse Valve



Submerged pulse jet valve: The valve body full immerse in the intake air bags, direct control of the diaphragm valve by electrical signals.



Working principle:

The pulse jet valve diaphragm into before and after two of the gas chamber, when switching compressed air, compressed air through the orifice of the gas chamber after entering, and at the time of the gas chamber pressure after the valve diaphragm components will close to losing exports, electromagnetic pulse valve is in "off" status.



Pulse jet control instrument signal that the pulse jet valve bit back, after the gas chamber put stomatal open, and the gas chamber pressure loss after quickly, diaphragm components moved, compressed air through the valve lose export injection, pulse jet valve in the "open" status.



Pulse jet control instrument signal disappears, pulse jet valve bit reset, and the gas chamber after put stomatal closure, the gas chamber pressure after that close to the valve diaphragm component output, pulse jet valve and in "off" status.



Technical data of Full Immerse Pulse Jet Valve:

Model No
CA25MM
CA40MM
CA50MM
CA62MM
CA76MM
CA102MM
Nominal Size
25
40
50
62
76
102
Port Size
mm
25
40
50
62
76
102
inch
1''
1 1/2''
2''
2 1/2''
3''
3 1/2''
4''
Pressure Range
0.3 to 0.8MPa
Temp.
Range
Nitrile seals
-40 to 82℃
Viton seals
-29 to 232℃


Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.


Main Dimension of CA76MM Pulse Jet Valve:

3 Inch CA76MM Goyen Type Submerged Dust Collector Pulse Valve 0

Detail images of Goyen Type Pulse Jet Valves:

3 Inch CA76T Goyen Type Dust Collector Solenoid Valve 1



Video of CA76MM Goyen Type Pulse Jet Valve:



More Goyen Type Pulse Valve For You to Choose:


3 Inch CA76T Goyen Type Dust Collector Solenoid Valve 23 Inch CA76T Goyen Type Dust Collector Solenoid Valve 33 Inch CA76T Goyen Type Dust Collector Solenoid Valve 43 Inch CA76T Goyen Type Dust Collector Solenoid Valve 5

       Threaded Type                 Immersion Type                Dresser Nut Type               Flanged Type

3 Inch CA76T Goyen Type Dust Collector Solenoid Valve 63 Inch CA76T Goyen Type Dust Collector Solenoid Valve 73 Inch CA76T Goyen Type Dust Collector Solenoid Valve 83 Inch CA76T Goyen Type Dust Collector Solenoid Valve 9

        RCA Series                          Solenoid Coil                 Armature Assembly           Pulse Controller
