Goyen Type Diaphragm Valve CA76MM010 CA76MM010-300 CA76MM010-305
The great operating-performance of dust collector full immerse pulse jet valve reflects in: Sensitive and reliable signal, Low internal-resistance, Large gas-displacement, High airflow impact-force, Stable working, Long operating-life.
The technical characteristics of our Pulse Jet Valve:
1. Vacuum treatment for solenoid coil to eliminate harmful impurities, it makes the pilot work more sensative and reliable;
2. Orifice and unloading port match with the pulse valve, fast opening and closing, so it increases the blowing volume per unit time;
3. Membrane: Effective bonding and Sufficient tensile strength, Reliable sealing, Great anti-corrosion and anti-aging properties, we use high-performance diaphragm so that it ensures long-term operation reliability.
4. We are using high-quality pressure spring to guarantee at least 1 millon times of service life.
Technical data of Full Immerse Pulse Jet Valve:
Model No
CA25MM
CA40MM
CA50MM
CA62MM
CA76MM
CA102MM
Nominal Size
25
40
50
62
76
102
Port Size
mm
25
40
50
62
76
102
inch
1''
1 1/2''
2''
2 1/2''
3''
3 1/2''
4''
Pressure Range
0.3 to 0.8MPa
Temp.
Range
Nitrile seals
-40 to 82℃
Viton seals
-29 to 232℃
Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.
Main Dimension of CA76MM Pulse Jet Valve:
Detail images of Goyen Type Pulse Jet Valves:
Video of CA76MM Goyen Type Pulse Jet Valve:
More Goyen Type Pulse Valve For You to Choose:
Threaded Type Immersion Type Dresser Nut Type Flanged Type
RCA Series Solenoid Coil Armature Assembly Pulse Controller
