Home ProductsPulse Jet Valve

3'' CA76MM040-305 CA76MM040-300 Goyen Type Pulse Jet Valve

3'' CA76MM040-305 CA76MM040-300 Goyen Type Pulse Jet Valve

3'' CA76MM040-305 CA76MM040-300 Goyen Type Pulse Jet Valve
3'' CA76MM040-305 CA76MM040-300 Goyen Type Pulse Jet Valve

Product Details:

Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: CA76MM

Payment & Shipping Terms:

Minimum Order Quantity: 1
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union, Paypal, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: Pulse Jet Valve Valve Type: Full Immersion
Port Size: 3'' Diaphragm Material: NBR
Working Pressure Range: 0.3 To 0.8 MPa Voltage: 24VDC, 220VAC
High Light:

Pulse Jet Valve 3''

,

Goyen Pulse Jet Valve

,

Goyen CA76MM040-305

3'' CA76MM040-305 CA76MM040-300 Goyen Type Pulse Jet Valve​


Dust collector reverse pulse jet valves, immersion type, are the filter cleaning components for baghouses (dust collection systems) for preventing dust explosions by removing particulates from the air.



Pulse jet valve will open and close rapidly to create a short, intense blast of air with sonic shock wave to dislodge accumulated dust from bag filters and cartridge filters without disrupting regular operations.



For Industries:
1. Abrasive Blasting (Parts Cleaning)
2. Asphalt, Concrete and Aggregates
3. Fertilizer
4. Forestry and Lumber
5. Grain and Agriculture
6. Metal Fabrication (Cutting, Grinding, Machining)
7. Mining
8. Paper and Pulp Processing
9. Pharmaceutical Processing
10. Powder and Bulk Solids Handling
11. Power Generation (Gas Turbines)
12. Rubber Processing
13. Steel and Smelting



Technical data of Full Immerse Pulse Jet Valve:

Model No
CA25MM
CA40MM
CA50MM
CA62MM
CA76MM
CA102MM
Nominal Size
25
40
50
62
76
102
Port Size
mm
25
40
50
62
76
102
inch
1''
1 1/2''
2''
2 1/2''
3''
3 1/2''
4''
Pressure Range
0.3 to 0.8MPa
Temp.
Range
Nitrile seals
-40 to 82℃
Viton seals
-29 to 232℃


Tips: All related accessories are also sold, like Pulse Controller, Diaphragm Repair Kit, Solenoid Valve Coil and Solenoid Valve Armature Assembly.


Main Dimension of CA76MM Pulse Jet Valve:

3'' CA76MM040-305 CA76MM040-300 Goyen Type Pulse Jet Valve 0

Detail images of Goyen Type Pulse Jet Valves:

3 Inch CA76T Goyen Type Dust Collector Solenoid Valve 1



Video of CA76MM Goyen Type Pulse Jet Valve:



More Goyen Type Pulse Valve For You to Choose:


3 Inch CA76T Goyen Type Dust Collector Solenoid Valve 23 Inch CA76T Goyen Type Dust Collector Solenoid Valve 33 Inch CA76T Goyen Type Dust Collector Solenoid Valve 43 Inch CA76T Goyen Type Dust Collector Solenoid Valve 5

       Threaded Type                 Immersion Type                Dresser Nut Type               Flanged Type

3 Inch CA76T Goyen Type Dust Collector Solenoid Valve 63 Inch CA76T Goyen Type Dust Collector Solenoid Valve 73 Inch CA76T Goyen Type Dust Collector Solenoid Valve 83 Inch CA76T Goyen Type Dust Collector Solenoid Valve 9

        RCA Series                          Solenoid Coil                 Armature Assembly           Pulse Controller



Focus on your demands, Offer you best solution:


√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing



Welcome to your any problem and inquiry!
