3 Inch CA76T Goyen Type Dust Collector Solenoid Valve

3 Inch CA76T Goyen Type Dust Collector Solenoid Valve

3 Inch CA76T Goyen Type Dust Collector Solenoid Valve
video
3 Inch CA76T Goyen Type Dust Collector Solenoid Valve
Product Details:
Place of Origin: CHINA
Brand Name: BRANDO
Certification: CE
Model Number: CA76T
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box,Carton,Pallet
Delivery Time: 4-7 days
Payment Terms: T/T, Western Union, L/C, MoneyGram
Supply Ability: 165000 pieces per month
Contact Now
Detailed Product Description
Port Size: 3'' Coil Voltage: 24VDC, 220VAC
Working Pressure Range: 0.3 To 0.8MPa Threaded Pulse Jet Valve: CA15T, CA20T, CA25T, CA35T, CA45T, CA50T, CA62T, CA76T
Dresser Nut Pulse Jet Valve: CA25DD, RCA25DD, CA45DD Immersion Pulse Jet Valve: CA50MM, CA62MM, CA76MM, CA89MM
Flanged Pulse Jet Valve: CAC25FS, CAC45FS Remote Pilot Pulse Jet Valve: RCA25DD, RCA20T, RCA45T, RCA50T, RCA62T
Application: Cartridge Filters, Envelope Filters, Ceramic Filters, Sintered Metal Fiber Filters
High Light:

Goyen Solenoid Valve

,

Dust Collector Solenoid Valve

,

Goyen Dust Collector Valve

3 Inch CA76T Goyen Type Dust Collector Solenoid Valve



This is CA76T Goyen Type Right Angle Pulse Jet Valve; Reference No: CA76T000, CA76T001, CA76T010, CA76T000-300, CA76T001-300, CA76T010-300, CA76T000-305, CA76T001-305, CA76T010-305, CA76T000-331, CA76T001-331, CA76T010-331. Threaded port connection; NBR diaphragm; 24V DC, 220V AC (50/60Hz) voltages for you to choose; other voltages can be customized.



Description:



This series of pulse jet valves includes models with threaded connections from 3/4'' to 3''. These valves are particular used for reverse pulse-jet filter cleaning of filter bags, cartridges, envelope filters, ceramic filters and sintered metal fibre filters.



They have an inlet port at 90° to the outlet port.



The pulse jet valves differ in types with an integrated pilot valve or with external pneumatic control.



The special design ensures extremely fast opening, high flow and easy installation.



Optionally, we also offer versions with ATEX certified pilot valves.



A well thought-out structure and a fast delivery time for spare parts such as diaphragms, springs and coils enable simple maintenances.



Technical data of Right Angle Pulse Jet Valves:

Model No
CA15T
CA20T
CA25T
CA35T
CA45T
CA50T
CA62T
CA76T
Nonimal size
φ15
φ20
φ25
φ35
φ45
φ50
φ62
φ76
Port Size
G1/2''
G3/4''
G1''
G1 1/4''
G1 1/2''
G2''
G2 1/2''
G3''
Working pressure
0.3 to 0.8MPa
Temp. range
-5℃ to 55℃
Relative humidity
≤85%
Working
medium
Compressed clean air
Voltage
24VDC, 220VAC



Dimension of CA76T Goyen Type Pulse Jet Valve:

3 Inch CA76T Goyen Type Dust Collector Solenoid Valve 0



Video of CA76T Goyen Type Pulse Jet Valve:



Detail images of Goyen Type Pulse Jet Valves:

3 Inch CA76T Goyen Type Dust Collector Solenoid Valve 1



More Goyen Type Pulse Valve For You to Choose:


3 Inch CA76T Goyen Type Dust Collector Solenoid Valve 23 Inch CA76T Goyen Type Dust Collector Solenoid Valve 33 Inch CA76T Goyen Type Dust Collector Solenoid Valve 43 Inch CA76T Goyen Type Dust Collector Solenoid Valve 5

       Threaded Type                   Immersion Type                Dresser Nut Type             Flanged Type

3 Inch CA76T Goyen Type Dust Collector Solenoid Valve 63 Inch CA76T Goyen Type Dust Collector Solenoid Valve 73 Inch CA76T Goyen Type Dust Collector Solenoid Valve 83 Inch CA76T Goyen Type Dust Collector Solenoid Valve 9

          RCA Series                          Solenoid Coil                Armature Assembly            Pulse Controller
