720 DIN 46350A IP65 Vertical Repeat Cycle Timer For Solenoid Valves

720 DIN 46350A IP65 Vertical Repeat Cycle Timer For Solenoid Valves

Solid State analogue cycle timer. Cycles from 0.5 to 10 seconds on and 0.5 to 45 minutes off which is set by adjusting external knobs. Sandwiches between the DIN plug and coil on a solenoid valve to integrate a timing function. Comes with LED on and off indicators and a manual test button and designed to take any voltage (24 to 240v AC/DC).

Key features:
1. Available off cycle: 0.5 to 10 seconds, 0.5 to 45 minutes, 0.5 to 60 minutes and 25 to 150 minutes.
2. Available on cycle: 0.5 to 10 seconds, 0.25 to 5 minutes, 0.5 to 10 minutes and 0.5 to 45 minutes.
3. Ambient temperature: -40°C to +60°C.
4. CE Tested.
5. Fully automatic - no maintenance required. Simple to install.

Solenoid valve timers can be used to control your solenoid valves according to a desired schedule. Most timers can be directly mounted on the solenoid valve coils via a DIN-A connector. They can be used for example for air dryers, shower timers, condensate drains, lubrication systems etc. We offer analog and digital timers, both suitable for AC and DC.

Technical Data of Solenoid Valve Timer:

Main Dimension of Solenoid Valve Timer:

Installation of Solenoid Valve Timer:

More Timer Controlled Solenoid Valves for you to choose:

Applications
1. Sampling gas or Liquids
2. Air dryers
3. Effluent sampling
4. Sprinkler systems

Technical Specification
1. Auto drain valve: automatic discharge of condensate
2. Pneumatic vibration systems (e.g. Powder silos)
3. Automatic lubrication systems
4. Dosing systems
