Auto Drain Solenoid Valve Cyclic Timer For DIN 43650A Connector

Auto Drain Solenoid Valve Cyclic Timer For DIN 43650A Connector

Auto Drain Solenoid Valve Cyclic Timer For DIN 43650A Connector
video
Auto Drain Solenoid Valve Cyclic Timer For DIN 43650A Connector
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 720
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Product Name: Solenoid Valve Timer Series: 720
Theory: Countdown Usage: Timer Switch
Protection Class: IP65 Inrush Current: 10A For 10ms
Duty Cycle: 100%ED Time ON: From 0.5 To 10s
Time OFF: From 0.5 To 45 Min Indicators: Yellow LED
Manual Override: Test Termination: DIN 43650 Form A
High Light:

Solenoid Valve Cyclic Timer

,

Solenoid Valve Timer For DIN 43650A Connector

,

Automatic Drain Valve Countdown Timer

Auto Drain Solenoid Valve Cyclic Timer For DIN 43650A Connector



Solenoid valve timers can be used to control your solenoid valves according to a desired schedule. Most timers can be directly mounted on the solenoid valve coils via a DIN-A connector. They can be used for example for air dryers, shower timers, condensate drains, lubrication systems etc. We offer analog and digital timers, both suitable for AC and DC. Both models have LED indicators to indicate valve status.



Solenoid valve timers allow the user to automate the ON/OFF time of the solenoids valves in any pneumatic system. There are various different time cycles available, including:



1. Repeat Cycle: Enters the ON state for a period T1, then switches OFF for a period T2.
2. Single Shot: Enters the ON state for a period T, then switches OFF indefinitely.
3. Delay: Enters the OFF state for a period T, then switches ON indefinitely.
4. Delayed Repeat: Enters the OFF state for a period T2, then switches ON for a period T1.
5. Single Cycle: Enters the OFF state for a period T2, then switches ON for a period T1. It then switches OFF indefinitely.



Technical Data of Solenoid Valve Timer:

Supply voltage
24..240V AC/DC-50Hz/60Hz
Absorption current
4mA Max
Operating temperature
-10℃ to +50℃
Class protection
IP65-EN 60529
Switch holding voltage
400V Max
Switch capacity
1A
Inrush current
10A for 10ms
Duty cycle
100%ED
Switch life
3x10^8
Time ON
from 0.5 to 10s
Time OFF
from 0.5 to 45min
Indicators
Yellow LED
Manual override
Test
Termination
DIN43650A



Main Dimension of Solenoid Valve Timer:

BT-720A11



BT-720B12



Installation of Solenoid Valve Timer:

Auto Drain Solenoid Valve Cyclic Timer For DIN 43650A Connector 4



More Timer Controlled Solenoid Valves for you to choose:

Auto Drain Solenoid Valve Cyclic Timer For DIN 43650A Connector 5Auto Drain Solenoid Valve Cyclic Timer For DIN 43650A Connector 6

aaaaa


Applications
1. Sampling gas or Liquids
2. Air dryers
3. Effluent sampling
4. Sprinkler systems



Technical Specification
1. Auto drain valve: automatic discharge of condensate
2. Pneumatic vibration systems (e.g. Powder silos)
3. Automatic lubrication systems
4. Dosing systems
