1/2'' 220V Timer Controlled Automatic Drain Valve For Compressed Air

1/2'' 220V Timer Controlled Automatic Drain Valve For Compressed Air

1/2'' 220V Timer Controlled Automatic Drain Valve For Compressed Air
video
1/2'' 220V Timer Controlled Automatic Drain Valve For Compressed Air
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BADV01
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Product Name: Air Compressor Automatic Drain Valve Port Size: 1/8'', 1/4'', 3/8'', 1/2''
Voltages: 24VDC, 110VAC, 220VAC Solenoid Coil: Class H, IP65
Seal Material: FKM Timer Cycle Range (ON / OFF): 0.5 To 10 Seconds / 0.5 To 45 Minutes
Application: Air Compressors, Air Receivers, Air Filters And Refrigerated Air Dryers.
High Light:

Automatic Drain Valve For Compressed Air

,

1/2'' Automatic Drain Valve

,

Timer Auto Drain Valve

1/2'' 220V Timer Controlled Automatic Drain Valve For Compressed Air



Timer drains are electrically operated units in which an adjustable timer periodically opens a valve to remove accumulated condensate. Timer drains are basic components used in most compressed air systems because they provide an inexpensive, reliable means of removing condensate without having to manually open drains’ valves. Timer drains are used on filters, air receivers, air dryers, separators, aftercoolers, and other compressed air system components.



They come equipped with valve and strainer to prevent entry of larger condensate, and a drain for the automatic removal of moisture. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining. The automatic drain valve also eliminates the need for the wasteful practice of bleeding, or leaving cracked open manual drain valves. With adjustable valve open and cycle time settings, all series drain valves can be set for your operating conditions. The valve open time may be set for 0.5 to 10 seconds and the cycle time may be set for 0.5 to 45 minutes.



Main Dimension of Air Compressor Automatic Drain Valve:

1/2'' 220V Timer Controlled Automatic Drain Valve For Compressed Air 0                        1/2'' 220V Timer Controlled Automatic Drain Valve For Compressed Air 1

Model
BADV01
BADV02
Port Size
1/8'', 1/4'', 3/8'', 1/2''
Valve Type
OPTIMUM
COMBO
Operation Type
2/2 Way, Direct Acting
Power Connection
DIN 43650 Form A
Voltages
24VDC, 110VAC, 220VAC (50/60Hz)
Body Material
Brass, Stainless Steel (For High Pressure)
Seal Material
FKM
Insulation Class
H
Protection Class
IP65
Timer Cycle Range (ON / OFF)
0.5 - 10seconds / 0.5 - 45 minutes
Timer Cycle Indicatin
Bright LED illumination
Test Feature
Yes
Pressure Range
0 - 230 PSI
Medium Temperature
34 - 131℉



Application Examples from customer feed back:

1/2'' 220V Timer Controlled Automatic Drain Valve For Compressed Air 2



Air Compressor Automatic Drain Valve Spare Parts:

auto drain valve timerauto drain valve parts solenoid coilauto drain valve parts

              Solenoid Valve Timer                              Solenoid Valve Coil                           Solenoid Valve Armature
