Timer Controlled Air Compressor Auto Drain Valve 1/4'' 1/2'' 110V 220V

Timer Controlled Air Compressor Auto Drain Valve 1/4'' 1/2'' 110V 220V

Timer Controlled Air Compressor Auto Drain Valve 1/4'' 1/2'' 110V 220V
video
Timer Controlled Air Compressor Auto Drain Valve 1/4'' 1/2'' 110V 220V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BADV01
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Product Name: Air Compressor Automatic Drain Valve Port Size: 1/8'', 1/4'', 3/8'', 1/2''
Voltages: 24VDC, 110VAC, 220VAC Solenoid Coil: Class H, IP65
Seal Material: FKM Timer Cycle Range (ON / OFF): 0.5 To 10 Seconds / 0.5 To 45 Minutes
Application: Air Compressors, Air Receivers, Air Filters And Refrigerated Air Dryers.
High Light:

Timer Auto Drain Valve

,

Auto Drain Valve 1/2''

,

Auto Drain Valve 220V

Timer Controlled Air Compressor Auto Drain Valve 1/4'' 1/2'' 110V 220V



The OPTIMUM automatic drain valve is a full-feature automatic electronic solenoid drain valve that cost-effectively removes condensate from compressors, receivers, dryers, aftercoolers, filters and drip legs. Each one includes an electric drain, manual blowdown valve, and a strainer/ball valve, which prevents debris from clogging the drain valve.



Benefits:

1. Does not air-lock during operation.

2. Compressed air systems up to any size.

3. Also available in stainless steel.

4. The direct acting valve is serviceable.

5. Suitable for all types of compressors.

6. Test (micro-switch) feature – test to ensure operating correctly

7. Retains cycle accuracy.

8. Premium PCB components.

9. Large (4.5 mm) valve orifice.

10. Medium pressure up to 16 Bar



Main Dimension of Air Compressor Automatic Drain Valve:

Timer Controlled Air Compressor Auto Drain Valve 1/4'' 1/2'' 110V 220V 0                        Timer Controlled Air Compressor Auto Drain Valve 1/4'' 1/2'' 110V 220V 1

Model
BADV01
BADV02
Port Size
1/8'', 1/4'', 3/8'', 1/2''
Valve Type
OPTIMUM
COMBO
Operation Type
2/2 Way, Direct Acting
Power Connection
DIN 43650 Form A
Voltages
24VDC, 110VAC, 220VAC (50/60Hz)
Body Material
Brass, Stainless Steel (For High Pressure)
Seal Material
FKM
Insulation Class
H
Protection Class
IP65
Timer Cycle Range (ON / OFF)
0.5 - 10seconds / 0.5 - 45 minutes
Timer Cycle Indicatin
Bright LED illumination
Test Feature
Yes
Pressure Range
0 - 230 PSI
Medium Temperature
34 - 131℉



Application Examples from customer feed back:

Timer Controlled Air Compressor Auto Drain Valve 1/4'' 1/2'' 110V 220V 2



Air Compressor Automatic Drain Valve Spare Parts:

auto drain valve timerauto drain valve parts solenoid coilauto drain valve parts

              Solenoid Valve Timer                              Solenoid Valve Coil                           Solenoid Valve Armature



Brando Solenoid Valve Factory Production Video:



More Air Compressor Solenoid Valve for you to choose:

Timer Controlled Air Compressor Auto Drain Valve 1/4'' 1/2'' 110V 220V 6Timer Controlled Air Compressor Auto Drain Valve 1/4'' 1/2'' 110V 220V 7

Timer Controlled Air Compressor Auto Drain Valve 1/4'' 1/2'' 110V 220V 8Timer Controlled Air Compressor Auto Drain Valve 1/4'' 1/2'' 110V 220V 9
