1/4'' 1/2'' Jorc Type Air Compressor Automatic Drain Valve 110V 220V

1/4'' 1/2'' Jorc Type Air Compressor Automatic Drain Valve 110V 220V

Air Compressor automatic drain valve is a valve that operates regularly and periodically, opening for a specified length of time on a predetermined basis, and uses electricity to provide the power and the timing function. You can see the power supply and the two adjustment knobs. One of these adjusts the frequency of valve operation, and the other adjusts the length of time that the valve opens each time the timer turns on the power. This model has a manual ball valve installed as well, which is sometimes useful as an override.

The strategic use of air compressor automatic drain valve: one in the drain port of every tank or air reservoir, and one at every drop leg where compressed air is plumbed down to the air tool, will go a long way in ridding your air system of water.

Frequent and thorough draining of the air tank helps maintain the integrity of the air tank as well, since regular draining keeps the tank dry, helping to eliminate rust over the long haul.

Benefits:

1. Does not air-lock during operation.

2. Compressed air systems up to any size.

3. Also available in stainless steel.

4. The direct acting valve is serviceable.

5. Suitable for all types of compressors.

6. Test (micro-switch) feature – test to ensure operating correctly

7. Retains cycle accuracy.

8. Premium PCB components.

9. Large (4.5 mm) valve orifice.

10. Medium pressure up to 16 Bar

Main Dimension of Air Compressor Automatic Drain Valve:

Application Examples from customer feed back:

Air Compressor Automatic Drain Valve Spare Parts:

              Solenoid Valve Timer                              Solenoid Valve Coil                           Solenoid Valve Armature
