1/2'' Automatic Condensate Drain Valve For Air Receiver Tank

1/2'' Automatic Condensate Drain Valve For Air Receiver Tank

The automatic drain valve assembly consists of a solid-state timer coupled to a solenoid valve. The solenoid timer let you set the drain to come on once every 10 seconds to 45 minutes and remain open for 0.10 to 10 seconds. The unit is suitable for ALL compressed air system components (aftercoolers, dryers, filters, pressure vessels and piping), regardless of their size or capacity - simply adjust the interval and discharge times to suit the particular compressed air system.

Benefits:
1. Does not air-lock during operation
2. Compressed air systems up to any size
3. Also available in stainless steel (230 - 6,000 psi)
4. The direct acting valve is serviceable
5. Suitable for all types of compressors
6. TEST (micro-switch) feature
7. 1 year warranty

Advantages:
1. High time cycle accuracy
2. Premium pcb components selected
3. Large (4.5mm/0.18in) valve orifice
4. Medium pressure up to 230 psi (for higher see Optimum HP)

Main Dimension of Air Compressor Automatic Drain Valve:

Application Examples from customer feed back:

Air Compressor Automatic Drain Valve Spare Parts:

              Solenoid Valve Timer                              Solenoid Valve Coil                           Solenoid Valve Armature
