1/2'' Air Compressor Automatic Drain Valve With Timer 220V

1/2'' Air Compressor Automatic Drain Valve With Timer 220V

1/2'' Air Compressor Automatic Drain Valve With Timer 220V
video
1/2'' Air Compressor Automatic Drain Valve With Timer 220V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BADV02
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Product Name: Air Compressor Auto Drain Valve Port Size: 1/8'', 1/4'', 3/8'', 1/2''
Voltages: 24VDC, 110VAC, 220VAC Solenoid Coil: Class H, IP65
Seal Material: VITON (FKM) Timer Cycle Range (ON / OFF): 0.5 To 10seconds / 0.5 To 45 Minutes
Application: Air Compressors, Air Receivers, Air Filters And Refrigerated Air Dryers.
High Light:

Automatic Drain Valve With Timer

,

Automatic Electronic Timer Drain Valve

,

Automatic Drain Valve 220V

1/4'' 1/2'' Automatic Drain Valve For Air Compressor 110V 220V



Automatic drain valves are designed to drain out the air filter condensate comprising of oil, water, and air build-up in the various elements of an air compressor system. They come equipped with valve and strainer to prevent entry of larger condensate, and a drain for the automatic removal of moisture. The inexpensive and reliable automatic drain valve automatically removes condensate from your air system. It has an integral strainer to prevent clogging and saves time and money by eliminating the need for manual draining. The automatic drain valve also eliminates the need for the wasteful practice of bleeding, or leaving cracked open manual drain valves. With adjustable valve open and cycle time settings, all series drain valves can be set for your operating conditions. The valve open time may be set for 0.5 to 10 seconds and the cycle time may be set for 0.5 to 45 minutes.



Main Dimension of Air Compressor Automatic Drain Valve:

1/2'' Air Compressor Automatic Drain Valve With Timer 220V 0  1/2'' Air Compressor Automatic Drain Valve With Timer 220V 1

Model
BADV01
BADV02
Port Size
1/8'', 1/4'', 3/8'', 1/2''
Valve Type
OPTIMUM
COMBO
Operation Type
2/2 Way, Direct Acting
Power Connection
DIN 43650 Form A
Voltages
24VDC, 110VAC, 220VAC (50/60Hz)
Body Material
Brass, Stainless Steel (For High Pressure)
Seal Material
FKM
Insulation Class
H
Protection Class
IP65
Timer Cycle Range (ON / OFF)
0.5 - 10seconds / 0.5 - 45 minutes
Timer Cycle Indicatin
Bright LED illumination
Test Feature
Yes
Pressure Range
0 - 230 PSI
Medium Temperature
34 - 131℉



Application Examples from customer feed back:

1/2'' Air Compressor Automatic Drain Valve With Timer 220V 2



Air Compressor Automatic Drain Valve Spare Parts:

auto drain valve timerauto drain valve parts solenoid coilauto drain valve parts

              Solenoid Valve Timer                              Solenoid Valve Coil                           Solenoid Valve Armature



Brando Solenoid Valve Factory Production Video:



More Air Compressor Solenoid Valve for you to choose:

1/2'' Air Compressor Automatic Drain Valve With Timer 220V 61/2'' Air Compressor Automatic Drain Valve With Timer 220V 7

1/2'' Air Compressor Automatic Drain Valve With Timer 220V 81/2'' Air Compressor Automatic Drain Valve With Timer 220V 9



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
