1/2 Inch 220V Air Compressor Automatic Drain Valve For Condensate

1/2 Inch 220V Air Compressor Automatic Drain Valve For Condensate

1/2 Inch 220V Air Compressor Automatic Drain Valve For Condensate
1/2 Inch 220V Air Compressor Automatic Drain Valve For Condensate

Product Details:

Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BADV01

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Product Name: Air Compressor Auto Drain Valve Port Size: 1/8'', 1/4'', 3/8'', 1/2''
Voltages: 24VDC, 110VAC, 220VAC Solenoid Coil: Class H, IP65
Valve Types: OPTIMUM, COMBO Valve Body Material: Brass, Stainless Steel (For High Pressure)
Seal Material: VITON (FKM) Timer Cycle Range (ON / OFF): 0.5 To 10seconds / 0.5 To 45 Minutes
Timer Cycle Indicatin: Bright LED Illumination Application: Air Compressors, Air Receivers, Air Filters And Refrigerated Air Dryers.
High Light:

Automatic Drain Valve For Condensate

,

Automatic Drain Valve 220V

,

Automatic Drain Valve 1/2 Inch

1/2 Inch 220V Air Compressor Automatic Drain Valve For Condensate



Air Compressor automatic drain valve is a valve that operates regularly and periodically, opening for a specified length of time on a predetermined basis, and uses electricity to provide the power and the timing function. You can see the power supply and the two adjustment knobs. One of these adjusts the frequency of valve operation, and the other adjusts the length of time that the valve opens each time the timer turns on the power. This model has a manual ball valve installed as well, which is sometimes useful as an override.



The strategic use of air compressor automatic drain valve: one in the drain port of every tank or air reservoir, and one at every drop leg where compressed air is plumbed down to the air tool, will go a long way in ridding your air system of water.

Frequent and thorough draining of the air tank helps maintain the integrity of the air tank as well, since regular draining keeps the tank dry, helping to eliminate rust over the long haul.



Main Dimension of Air Compressor Automatic Drain Valve:

1/2 Inch 220V Air Compressor Automatic Drain Valve For Condensate 0  1/2 Inch 220V Air Compressor Automatic Drain Valve For Condensate 1

Model
BADV01
BADV02
Port Size
1/8'', 1/4'', 3/8'', 1/2''
Valve Type
OPTIMUM
COMBO
Operation Type
2/2 Way, Direct Acting
Power Connection
DIN 43650 Form A
Voltages
24VDC, 110VAC, 220VAC (50/60Hz)
Body Material
Brass, Stainless Steel (For High Pressure)
Seal Material
FKM
Insulation Class
H
Protection Class
IP65
Timer Cycle Range (ON / OFF)
0.5 - 10seconds / 0.5 - 45 minutes
Timer Cycle Indicatin
Bright LED illumination
Test Feature
Yes
Pressure Range
0 - 230 PSI
Medium Temperature
34 - 131℉



Application Examples from customer feed back:

1/2 Inch 220V Air Compressor Automatic Drain Valve For Condensate 2



Air Compressor Automatic Drain Valve Spare Parts:

auto drain valve timerauto drain valve parts solenoid coilauto drain valve parts

              Solenoid Valve Timer                              Solenoid Valve Coil                           Solenoid Valve Armature
