1/4'' 1/2'' Jorc Type Air Compressor Automatic Drain Valve 220V

1/4'' 1/2'' Jorc Type Air Compressor Automatic Drain Valve 220V

1/4'' 1/2'' Jorc Type Air Compressor Automatic Drain Valve 220V
1/4'' 1/2'' Jorc Type Air Compressor Automatic Drain Valve 220V

Product Details:

Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BADV01

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 sets per month
Contact Now
Detailed Product Description
Product Name: Air Compressor Auto Drain Valve Port Size: 1/8'', 1/4'', 3/8'', 1/2''
Voltages: 24VDC, 110VAC, 220VAC Solenoid Coil: Class H, IP65
Seal Material: VITON (FKM) Timer Cycle Range (ON / OFF): 0.5 To 10seconds / 0.5 To 45 Minutes
Application: Air Compressors, Air Receivers, Air Filters And Refrigerated Air Dryers.
High Light:

1/2 Automatic Drain Valve

,

Automatic Condensate Drain Valve

,

Automatic Drain Valve For Air Compressor

1/4'' 1/2'' Jorc Type Air Compressor Automatic Drain Valve 220V



Automatic drain valve is used to replace the manual drains that are normally standard equipment on air compressor tanks. In order to keep free water from accumulating inside the receiver, and this is particularly important for industrial compressed air applications in which large compressors can dump gallons of water into a tank daily, this manual tank drain should be opened at least once a day to allow the tank to drain all water completely.



Depending on the size of your air compressor and the length of time that your air compressor runs each day, it might be necessary to drain water more frequently than that. Better to drain it too often than not enough.



The auto drain timer can be set both for the frequency of operation, and for the length of time (the duration) that the automatic drain valve is opened, to effectively and automatically rid the compressor tank of water that is generated by the compressing of air.



Main Dimension of Air Compressor Automatic Drain Valve:

1/4'' 1/2'' Jorc Type Air Compressor Automatic Drain Valve 220V 0  1/4'' 1/2'' Jorc Type Air Compressor Automatic Drain Valve 220V 1

Model
BADV01
BADV02
Port Size
1/8'', 1/4'', 3/8'', 1/2''
Valve Type
OPTIMUM
COMBO
Operation Type
2/2 Way, Direct Acting
Power Connection
DIN 43650 Form A
Voltages
24VDC, 110VAC, 220VAC (50/60Hz)
Body Material
Brass, Stainless Steel (For High Pressure)
Seal Material
FKM
Insulation Class
H
Protection Class
IP65
Timer Cycle Range (ON / OFF)
0.5 - 10seconds / 0.5 - 45 minutes
Timer Cycle Indicatin
Bright LED illumination
Test Feature
Yes
Pressure Range
0 - 230 PSI
Medium Temperature
34 - 131℉



Application Examples from customer feed back:

1/4'' 1/2'' Jorc Type Air Compressor Automatic Drain Valve 220V 2



Air Compressor Automatic Drain Valve Spare Parts:

auto drain valve timerauto drain valve parts solenoid coilauto drain valve parts

              Solenoid Valve Timer                              Solenoid Valve Coil                           Solenoid Valve Armature
