Airtac Type Pneumatic Air Solenoid Valve 1/4'' 4V210-08 AC220V AC110V

Airtac Type Pneumatic Air Solenoid Valve 1/4'' 4V210-08 AC220V AC110V

Airtac Type Pneumatic Air Solenoid Valve 1/4'' 4V210-08 AC220V AC110V
video
Airtac Type Pneumatic Air Solenoid Valve 1/4'' 4V210-08 AC220V AC110V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 4V210-08
Payment & Shipping Terms:
Minimum Order Quantity: 200pcs
Price: Negotiation
Packaging Details: Individual box, Carton, Pallet
Delivery Time: 15 working days
Payment Terms: T/T, PayPal, Western Union
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Product Name: Airtac Type Pneumatic Solenoid Valve Connector Type: Flyng Leads, DIN Connector
Voltages: 12VDC, 24VDC, 110VAC, 220VAC Fluid: Air (to Be Filtered By 40 μ M Filter Element)
Operation: Internal Pilot Or External Pilot Valve Type: Single Solenoid, 5 Way 2 Position
Pipe Size: Inlet=Outlet=1/4'', Exhaust=1/8'' Thread Type: G, NPT, PT, BSP
Valve Body Material: Aluminum Alloy Application: Pneumatic Cylinder, Pneumatic Actuator
High Light:

Airtac Solenoid Valve

,

5/2 Way Pneumatic Solenoid Valve

,

5 Way 2 Position Pneumatic Solenoid Valve

Airtac Type Pneumatic Air Solenoid Valve 1/4'' 4V210-08 AC220V AC110V



4V210-08 Airtac type pneumatic solenoid valve, single solenoid, 5/2 way, 1/4" inlet and outlet port size, 1/8'' exhaust port size, internal pilot, terminal entry, 200 series. Aluminum alloy body is strong. The valve body is made of new aluminum alloy material, which has strong pressure resistance, good corrosion resistance and fast heat dissipation; High quality seal ring. High-quality seals for durability and longer life; High-precision valve stem. Imported high-quality lubricant to ensure lubrication and reduce friction during exercise; High frequency sub head. Made of high-quality conductor material, it has 6 times higher strength and high frequency response in 1 second for smoother operation; The coil is easy to remove. Removable core nut, coil can be replaced at any time; High-quality electronic components. The copper coil can work for a long time, and the wiring operation is simple. LED lights when power is on; Pilot or diaphragm for controlling larger valves or small cylinders, or any pressure system that alternates pressurization and exhaust.



Data of 4V Series Pneumatic Solenoid Valves:

Model
4V210-06
4V220-06
4V230C-06
4V230E-06
4V230P-06
4V210-08
4V220-08
4V230C-08
4V230E-08
4V230P-08
Fluid
Air(to be filtered by 40 μ m filter element)
Acting
Internal pilot or external pilot
Port Size
In=Out=Exhaust=1/8''
In=Out=1/4'', Exhaust=1/8''
Orifice Size
25.00 mm2 (Cv=0.78)
18.00 mm2 (Cv=0.67)
30.00 mm2 (Cv=0.89)
18.00 mm2 (Cv=0.67)
Valve Type
5 port 2 position
5 port 3 position
5 port 2 position
5 port 3 position
Operating Pressure
0.15~0.8MPa (21~114psi)
Proof Pressure
1.5MPa (215psi)
Temperature ℃
-5~50
Material of Body
Aluminum alloy
Max. frequency
5 cycle/sec
3 cycle/sec
5 cycle/sec
3 cycle/sec



Product Video of 4V210-08 Pneumatic Solenoid Valve:



Main dimension of 4V210-08 Pneumatic Solenoid Valve:

4V210-08 5/2 Way Pneumatic Solenoid Valve



More Pneumatic Solenoid Valves for you to choose:

4v1004v210-084v300a1

*4V100 Pneumatic Valves       *4V200 Pneumatic Valves    *4V300 Pneumatic Valves    *4V400 Pneumatic Valves

a1 a1 a3pneumatic fast fittings

*5/2 Way Pneumatic Valve *5/3 Way Pneumatic Valve       *2/2 Way Pneumatic Valve     *Pneumatic Fast Fitting



Brando offers multiple port and position configurations. Most air control valves are available with 220VAC, 110VAC, 24VDC or 12VDC solenoid coils. Select from 5/2 way, 5/2 way or 3/2 way.



Brando Supply:
1. 5/2 Way Pneumatic Solenoid Valve: 4V110-06, 4V120-06, 4V210-06, 4M220-06, 4V210-08, 4V220-08, 4V310-08, 4V320-08, 4V310-10, 4V410-15, 4V420-15, 4M110-06, 4M120-06, 4M210-06, 4M220-06, 4M210-08, 4M220-08, 4M310-08, 4M320-08, 4M310-10, 4M320-10


2. 5/3 Way Pneumatic Solenoid Valve: 4V130C-06, 4V130E-06, 4V130P-06, 4V230C-06, 4V230E-06, 4V230P-06, 4V230C-08, 4V230E-08, 4V230P-08, 4V330C-08, 4V330E-08, 4V330P-08, 4V330C-10, 4V330E-10, 4V330P-10, 4V430C-15, 4V430E-15, 4V430P-15


3. 2/2 Way Pneumatic Solenoid Valve: 2V025-06, 2V025-08
