| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4V420-15 |
| Minimum Order Quantity: | 100pcs |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T, PayPal, Western Union |
| Supply Ability: | 100000 pcs per month |
| Product Name: | Airtac Type Pneumatic Solenoid Valve | Valve Type: | Double Solenoid, 5 Way 2 Position |
|---|---|---|---|
| Fluid: | Air (to Be Filtered By 40 μ M Filter Element) | Body Material: | Aluminum Alloy |
| Action: | Internal Pilot Or External Pilot | Pipe Sizes: | In=Out=Exhaust=1/2'' |
| Thread Type: | G, PT, NPT, BSP | Voltages: | 220V AC, 110V AC, 24V AC, 24V DC, 12V DC |
| Highlight: | Airtac Solenoid Valve,5/2 Way Pneumatic Solenoid Valve,5 Way 2 Position Pneumatic Solenoid Valve |
||
5 Way 2 Position Pneumatic Solenoid Valve Airtac Type 4V420-15 12V 24V
This is a 4V420-15 Airtac type pneumatic solenoid valve, 1/2'' inlet and out let size, female thread (G, NPT, PT, BSP) connection, double solenoid, 5 way 2 position, several standard voltage levels are optional (12V DC, 24V DC, 110V AC, 220V AC).
Directional control valves are used in pneumatic systems to direct or stop the flow of compressed air or oil to their equipment. They are probably the most commonly used components in pneumatic systems, such as those used to drive cylinders, larger industrial valves or pneumatic tools. The valve can have two or more ports and can perform various circuit functions. The function and behavior of the valve can be represented by symbols. However, this symbol does not indicate the structure of the valve. The directional control valve can be operated in different ways, such as manual operation or solenoid operation.
Data of 4V400 Series Pneumatic Solenoid Valves:
|
Model
|
4v410-15
|
4V420-15
|
4V430C-15
|
4V430E-15
|
4V430P-15
|
|
Fluid
|
Air(to be filtered by 40 μ m filter element)
|
||||
|
Acting
|
Internal pilot or external pilot
|
||||
|
Port Size
|
In=Out=Exhaust=1/2''
|
||||
|
Orifice Size
|
50.00 mm² (Cv=2.79)
|
30.00 mm² (Cv=1.68)
|
|||
|
Valve Type
|
5 port 2 position
|
5 port 3 position
|
|||
|
Operating Pressure
|
0.15~0.8MPa (21~114psi)
|
||||
|
Proof
|
1.5MPa (215psi)
|
||||
|
Temperature ℃
|
-20 to 70
|
||||
|
Material of Body
|
Aluminum alloy
|
||||
|
Max. frequency
|
3cycle/sec
|
||||
Product video of 4V420-15 Pneumatic Solenoid Valve:
Main dimension of 4V420-15 Pneumatic Solenoid Valve:
Brando Factory Production of Pneumatic Solenoid Valves:
More Pneumatic Solenoid Valves for you to choose:
Brando is a Pneumatic Valve manufacturer and exporter in Ningbo, China, which has more than 10 years experience. The most common types are 2/2 way, 3/2 way, 5/2 way and 5/3 way. The valves can be single or double acting (one or two solenoids).
Brando Supply:
1. 5/2 Way Pneumatic Solenoid Valve: 4V110-06, 4V120-06, 4V210-06, 4M220-06, 4V210-08, 4V220-08, 4V310-08, 4V320-08, 4V310-10, 4V410-15, 4V420-15, 4M110-06, 4M120-06, 4M210-06, 4M220-06, 4M210-08, 4M220-08, 4M310-08, 4M320-08, 4M310-10, 4M320-10
2. 5/3 Way Pneumatic Solenoid Valve: 4V130C-06, 4V130E-06, 4V130P-06, 4V230C-06, 4V230E-06, 4V230P-06, 4V230C-08, 4V230E-08, 4V230P-08, 4V330C-08, 4V330E-08, 4V330P-08, 4V330C-10, 4V330E-10, 4V330P-10, 4V430C-15, 4V430E-15, 4V430P-15
3. 2/2 Way Pneumatic Solenoid Valve: 2V025-06, 2V025-08
