| Place of Origin: | China |
| Brand Name: | Brando |
| Certification: | CE |
| Model Number: | 4V410-15 |
| Minimum Order Quantity: | 1 pc |
|---|---|
| Price: | $4 to $10 per pc |
| Packaging Details: | Individual box, Carton, Pallet |
| Delivery Time: | 4-8 days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 100000 pcs per month |
| Product Name: | Airtac Type Pneumatic Solenoid Valve | Pipe Sizes: | In=Out=Exhaust=1/2'' |
|---|---|---|---|
| Thread Type: | G, PT, NPT, BSP | Valve Type: | Single Solenoid, 5 Way 2 Position |
| Body Material: | Aluminum Alloy | Voltages: | 220V AC, 110V AC, 24V AC, 24V DC, 12V DC |
| High Light: | Airtac Solenoid Valve,5/2 Way Pneumatic Solenoid Valve,5 Way 2 Position Pneumatic Solenoid Valve |
||
5/2 Way Pneumatic Solenoid Valve Airtac Type 4V410-15 1/2" 220V 24V
This is a 4V410-15 Airtac type pneumatic solenoid valve, 1/2'' inlet and out let size, female thread (G, NPT, PT, BSP) connection, 5 way 2 position, several standard voltage levels are optional (12V DC, 24V DC, 110V AC, 220V AC).
Features:
1. Pilot mode: internal pilot or external pilot.
2. Sliding column structure: good sealing and sensitive response.
3. The three-position solenoid valve has three central functions for you to choose from.
4. The dual-control solenoid valve has a memory function.
5. The inner hole adopts special processing technology, which has low friction and wear, low starting pressure and long service life.
6. It can form an integrated valve group with the base to save installation space.
7. Equipped with attached manual equipment to facilitate installation and commissioning.
Product video of 4V410-15 Pneumatic Solenoid Valve:
Main dimension of 4V410-15 Pneumatic Solenoid Valve:
Data of 4V400 Series Pneumatic Solenoid Valves:
|
Model
|
4v410-15
|
4V420-15
|
4V430C-15
|
4V430E-15
|
4V430P-15
|
|
Fluid
|
Air(to be filtered by 40 μ m filter element)
|
||||
|
Acting
|
Internal pilot or external pilot
|
||||
|
Port Size
|
In=Out=Exhaust=1/2''
|
||||
|
Orifice Size
|
50.00 mm² (Cv=2.79)
|
30.00 mm² (Cv=1.68)
|
|||
|
Valve Type
|
5 port 2 position
|
5 port 3 position
|
|||
|
Operating Pressure
|
0.15~0.8MPa (21~114psi)
|
||||
|
Proof
|
1.5MPa (215psi)
|
||||
|
Temperature ℃
|
-20 to 70
|
||||
|
Material of Body
|
Aluminum alloy
|
||||
|
Max. frequency
|
3cycle/sec
|
||||
Brando Factory Production of Pneumatic Solenoid Valves:
More Pneumatic Solenoid Valves for you to choose:
Brando is a Pneumatic Valve manufacturer and exporter in Ningbo, China, which has more than 10 years experience. The most common types are 2/2 way, 3/2 way, 5/2 way and 5/3 way. The valves can be single or double acting (one or two solenoids).
Brando Supply:
1. 5/2 Way Pneumatic Solenoid Valve: 4V110-06, 4V120-06, 4V210-06, 4M220-06, 4V210-08, 4V220-08, 4V310-08, 4V320-08, 4V310-10, 4V410-15, 4V420-15, 4M110-06, 4M120-06, 4M210-06, 4M220-06, 4M210-08, 4M220-08, 4M310-08, 4M320-08, 4M310-10, 4M320-10
2. 5/3 Way Pneumatic Solenoid Valve: 4V130C-06, 4V130E-06, 4V130P-06, 4V230C-06, 4V230E-06, 4V230P-06, 4V230C-08, 4V230E-08, 4V230P-08, 4V330C-08, 4V330E-08, 4V330P-08, 4V330C-10, 4V330E-10, 4V330P-10, 4V430C-15, 4V430E-15, 4V430P-15
3. 2/2 Way Pneumatic Solenoid Valve: 2V025-06, 2V025-08
