4V320-08 Airtac Type Pneumatic Solenoid Valve 5 Way 2 Position 220VAC

4V320-08 Airtac Type Pneumatic Solenoid Valve 5 Way 2 Position 220VAC

4V320-08 Airtac Type Pneumatic Solenoid Valve 5 Way 2 Position 220VAC
video
4V320-08 Airtac Type Pneumatic Solenoid Valve 5 Way 2 Position 220VAC
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 4V320-08
Payment & Shipping Terms:
Minimum Order Quantity: 200 PCS
Packaging Details: Individual box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100000 pcs per month
Contact Now
Detailed Product Description
Product Name: AirTAC Type Pneumatic Solenoid Valve Pipe Sizes: Inlet=Outlet=Exhaust=1/4''
Thread Type: G, PT, NPT, BSP Valve Type: Double Solenoid, 5 Way 2 Position
Action: Internal Pilot Or External Pilot Body Material: Aluminum Alloy
Fluid: Air (to Be Filtered By 40 μ M Filter Element) Voltages: 220V AC, 110V AC, 24V AC, 24V DC, 12V DC
High Light:

Airtac Solenoid Valve

,

5/2 Way Pneumatic Solenoid Valve

,

5 Way 2 Position Pneumatic Solenoid Valve

4V320-08 Airtac Type Pneumatic Solenoid Valve 5 Way 2 Position 220VAC



This is 4V320-08 AirTAC type pneumatic solenoid valve, 1/4'' inlet, outlet & exhaust port size, double solenoid, 5 way 2 position, 12V DC, 24V DC, 110V AC, 220V AC volatges for you to choose, other voltages can be customized.



Advantages of our pneumatic solenoid valves:

1. Aluminum alloy body is strong. The valve body is made of new aluminum alloy material, which has strong pressure resistance, good corrosion resistance and fast heat dissipation;

2. High quality seal ring. High-quality seals for durability and longer life;

3. High-precision valve stem. Imported high-quality lubricant to ensure lubrication and reduce friction during exercise;

4. High frequency sub head. Made of high-quality conductor material, it has 6 times higher strength and high frequency response in 1 second for smoother operation;

5. The coil is easy to remove. Removable core nut, coil can be replaced at any time;

6. High-quality electronic components. The copper coil can work for a long time, and the wiring operation is simple. LED lights when power is on;

7. Pilot or diaphragm for controlling larger valves or small cylinders, or any pressure system that alternates pressurization and exhaust.



Product video of 4V320-08 Pneumatic Solenoid Valve:



Main dimension of 4V320-08 Pneumatic Solenoid Valve:

4V320-08



Data of 4V300 Series Pneumatic Solenoid Valves:

Model
4V310-08
4V320-08
4V330C-08
4V330E-08
4V330P-08
4V310-10
4V320-10
4V330C-10
4V330E-10
4V330P-10
Fluid
Air(to be filtered by 40 μ m filter element)
Acting
Internal pilot or external pilot
Port Size
In=Out=Exhaust=1/4''
In=Out=3/8'' Exhaust=1/4''
Orifice Size
25.00 mm2 (Cv=1.40)
18.00 mm2 (Cv=1.00)
30.00 mm2 (Cv=1.68)
18.00 mm2 (Cv=1.00)
Valve Type
5 port 2 position
5 port 3 position
5 port 2 position
5 port 3 position
Operating Pressure
0.15~0.8MPa(21~114psi)
Proof Pressure
1.5MPa(215psi)
Temperature ℃
5~50
Material of Body
Aluminum alloy
Max. frequency
4 cycle/sec
4 cycle/sec
4 cycle/sec
4 cycle/sec



Brando Factory Production of Pneumatic Solenoid Valves:



More Pneumatic Solenoid Valves for you to choose:

4v1004v210-084v300a1

*4V100 Pneumatic Valves       *4V200 Pneumatic Valves    *4V300 Pneumatic Valves    *4V400 Pneumatic Valves

a1 a1 a3pneumatic fast fittings

*5/2 Way Pneumatic Valve *5/3 Way Pneumatic Valve       *2/2 Way Pneumatic Valve     *Pneumatic Fast Fitting



Brando is a Pneumatic Valve manufacturer and exporter in Ningbo, China, which has more than 10 years experience. The most common types are 2/2 way, 3/2 way, 5/2 way and 5/3 way. The valves can be single or double acting (one or two solenoids).


Brando Supply:
1. 5/2 Way Pneumatic Solenoid Valve: 4V110-06, 4V120-06, 4V210-06, 4M220-06, 4V210-08, 4V220-08, 4V310-08, 4V320-08, 4V310-10, 4V410-15, 4V420-15, 4M110-06, 4M120-06, 4M210-06, 4M220-06, 4M210-08, 4M220-08, 4M310-08, 4M320-08, 4M310-10, 4M320-10


2. 5/3 Way Pneumatic Solenoid Valve: 4V130C-06, 4V130E-06, 4V130P-06, 4V230C-06, 4V230E-06, 4V230P-06, 4V230C-08, 4V230E-08, 4V230P-08, 4V330C-08, 4V330E-08, 4V330P-08, 4V330C-10, 4V330E-10, 4V330P-10, 4V430C-15, 4V430E-15, 4V430P-15


3. 2/2 Way Pneumatic Solenoid Valve: 2V025-06, 2V025-08



Focus on your demands, Offer you best solution:



√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing



Welcome to your any question and inquiry!
