1/8'' 4V130C-06 5/3 Way Pneumatic Solenoid Valve Airtac Type 220V

1/8'' 4V130C-06 5/3 Way Pneumatic Solenoid Valve Airtac Type 220V

  • 1/8'' 4V130C-06 5/3 Way Pneumatic Solenoid Valve Airtac Type 220V
  • 1/8'' 4V130C-06 5/3 Way Pneumatic Solenoid Valve Airtac Type 220V
  • 1/8'' 4V130C-06 5/3 Way Pneumatic Solenoid Valve Airtac Type 220V
1/8'' 4V130C-06 5/3 Way Pneumatic Solenoid Valve Airtac Type 220V
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: 4V130C-06
Payment & Shipping Terms:
Minimum Order Quantity: 1 pc
Price: $3 to $7 per pc
Packaging Details: Inner box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
Supply Ability: 200000 pcs per month
Contact Now
Detailed Product Description
Product Name: Airtac Type Pneumatic Solenoid Valve Position & Way: 5 Way 3 Position
Port Size: In=Out=1/8'' Thread Type: G, NPT, PT, BSP
Voltages: 12VDC, 24VDC, 110VAC, 220VAC Working Pressure Range: 0.15 To 0.8MPa
Operating Temperature: -5 To 50 ℃ Body Material: Aluminum Alloy
Fluid: 40 Micron Filtered Air Application: Pneumatic Cylinder, Pneumatic Actuator
High Light:

Airtac Solenoid Valve

,

5/3 Way Pneumatic Solenoid Valve

,

5 Way 3 Position Pneumatic Solenoid Valve

1/8'' 4V130C-06 5/3 Way Pneumatic Solenoid Valve Airtac Type 220V



This is a 4V130C-06 Airtac type pneumatic solenoid valve, 1/8'' inlet and out let size, female thread (G, NPT, PT, BSP) connection, 5 way 3 position, several standard voltage levels are optional (12V DC, 24V DC, 110V AC, 220V AC). It is widely used on pneumatic cylinder, pneumatic actuator, and other pneumatic cystems.



Features:
1. Pilot mode: internal pilot or external pilot.
2. Sliding column structure: good sealing and sensitive response.
3. The three-position solenoid valve has three central functions for you to choose from.
4. The dual-control solenoid valve has a memory function.
5. The inner hole adopts special processing technology, which has low friction and wear, low starting pressure and long service life.
6. It can form an integrated valve group with the base to save installation space.
7. Equipped with attached manual equipment to facilitate installation and commissioning.



Product Video of 4V130C-06 Pneumatic Solenoid Valve:





Main dimension of 4V130C-06 Pneumatic Solenoid Valve:

4V130-06

Technical data of 4V Series Pneumatic Solenoid Valves:

Model
4V110-06
4V120-06
4V130C-06
4V130E-06
4V130P-06
4V110-08
4V120-08
4V130C-08
4V130E-08
4V130P-08
Fluid
40 Micron Filtered Air
Operation
Internal pilot or external pilot
Ports Size
In=Out=1/8''
In=Out=1/4''
Orifice Size
5.5 mm² (Cv=0.31)
5.0 mm² (Cv=0.28)
12.00 mm² (Cv=0.67)
9.00 mm² (Cv=0.50)
Valve Type
5 Way 2 Position
5 Way 3 Position
5 Port 2 Position
5 Way 3 Position
Operating Pressure
0.15 to 0.8MPa (21 to 114psi)
Proof Pressure
1.5MPa (215psi)
Operating Temperature
-5 to 50
Body Material
Aluminum Alloy
Max. Frequency
5 cycle/sec
3 cycle/sec
5 cycle/sec
3 cycle/sec



Brando Factory Production of Pneumatic Solenoid Valves:



More Pneumatic Solenoid Valves for you to choose:

4v1004v210-084v300a1

*4V100 Pneumatic Valves     *4V200 Pneumatic Valves      *4V300 Pneumatic Valves     *4V400 Pneumatic Valves

a1 a1 a3pneumatic fast fittings

*5/2 Way Pneumatic Valve  *5/3 Way Pneumatic Valve       *2/2 Way Pneumatic Valve    *Pneumatic Fast Fitting



Brando is a Pneumatic Valve manufacturer and exporter in Ningbo, China, which has more than 10 years experience. The most common types are 2/2 way, 3/2 way, 5/2 way and 5/3 way. The valves can be single or double acting (one or two solenoids).


Brando Supply:
1. 5/2 Way Pneumatic Solenoid Valve: 4V110-06, 4V120-06, 4V210-06, 4M220-06, 4V210-08, 4V220-08, 4V310-08, 4V320-08, 4V310-10, 4V410-15, 4V420-15, 4M110-06, 4M120-06, 4M210-06, 4M220-06, 4M210-08, 4M220-08, 4M310-08, 4M320-08, 4M310-10, 4M320-10


2. 5/3 Way Pneumatic Solenoid Valve: 4V130C-06, 4V130E-06, 4V130P-06, 4V230C-06, 4V230E-06, 4V230P-06, 4V230C-08, 4V230E-08, 4V230P-08, 4V330C-08, 4V330E-08, 4V330P-08, 4V330C-10, 4V330E-10, 4V330P-10, 4V430C-15, 4V430E-15, 4V430P-15


3. 2/2 Way Pneumatic Solenoid Valve: 2V025-06, 2V025-08
