1/8'' NPT 4V110-06 Airtac Type Pneumatic Solenoid Valve 5/2 Way 24VDC

1/8'' NPT 4V110-06 Airtac Type Pneumatic Solenoid Valve 5/2 Way 24VDC

    • 1/8'' NPT 4V110-06 Airtac Type Pneumatic Solenoid Valve 5/2 Way 24VDC
    • 1/8'' NPT 4V110-06 Airtac Type Pneumatic Solenoid Valve 5/2 Way 24VDC
    • 1/8'' NPT 4V110-06 Airtac Type Pneumatic Solenoid Valve 5/2 Way 24VDC
  • 1/8'' NPT 4V110-06 Airtac Type Pneumatic Solenoid Valve 5/2 Way 24VDC

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: 4V110-06

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 pc
    Price: $3 to $7 per pc
    Packaging Details: Inner box, Carton, Pallet
    Delivery Time: 4-8 days
    Payment Terms: L/C, T/T, PayPal, Western Union, MoneyGram
    Supply Ability: 200000 pcs per month
    Contact Now
    Detailed Product Description
    Product Name: Airtac Type Pneumatic Solenoid Valve Position & Way: 5 Way 2 Position
    Port Size: In=Out=1/8'' Connection Type: Female Thread (G, NPT, PT, BSP)
    Voltages: 12VDC, 24VDC, 110VAC, 220VAC Body Material: Aluminum Alloy
    Fluid: 40 Micron Filtered Air Application: Pneumatic Cylinder, Pneumatic Actuator
    Working Pressure Range: 0.15 To 0.8MPa Operating Temperature: -5 To 50 ℃
    High Light:

    Airtac Solenoid Valve

    ,

    5/2 Way Pneumatic Solenoid Valve

    ,

    5 Way 2 Position Pneumatic Solenoid Valve

    1/8'' NPT 4V110-06 Airtac Type Pneumatic Solenoid Valve 5/2 Way 24VDC



    This is a 4V110-06 Airtac type pneumatic solenoid valve, 1/8'' inlet and out let size, female thread (G, NPT, PT, BSP) connection, 5 way 2 position, several standard voltage levels are optional (12V DC, 24V DC, 110V AC, 220V AC).



    Features:
    1. Pilot mode: internal pilot or external pilot.
    2. Sliding column structure: good sealing and sensitive response.
    3. The three-position solenoid valve has three central functions for you to choose from.
    4. The dual-control solenoid valve has a memory function.
    5. The inner hole adopts special processing technology, which has low friction and wear, low starting pressure and long service life.
    6. It can form an integrated valve group with the base to save installation space.
    7. Equipped with attached manual equipment to facilitate installation and commissioning.



    Technical data of 4V Series Pneumatic Solenoid Valves:

    Model
    4V110-06
    4V120-06
    4V130C-06
    4V130E-06
    4V130P-06
    4V110-08
    4V120-08
    4V130C-08
    4V130E-08
    4V130P-08
    Fluid
    40 Micron Filtered Air
    Operation
    Internal pilot or external pilot
    Ports Size
    In=Out=1/8''
    In=Out=1/4''
    Orifice Size
    5.5 mm² (Cv=0.31)
    5.0 mm² (Cv=0.28)
    12.00 mm² (Cv=0.67)
    9.00 mm² (Cv=0.50)
    Valve Type
    5 Way 2 Position
    5 Way 3 Position
    5 Port 2 Position
    5 Way 3 Position
    Operating Pressure
    0.15 to 0.8MPa (21 to 114psi)
    Proof Pressure
    1.5MPa (215psi)
    Operating Temperature
    -5 to 50
    Body Material
    Aluminum Alloy
    Max. Frequency
    5 cycle/sec
    3 cycle/sec
    5 cycle/sec
    3 cycle/sec



    Main dimension of 4V110-06 Pneumatic Solenoid Valve:

    4V110-06

    Product Video of 4V110-06 Pneumatic Solenoid Valve:



    Brando Factory Production of Pneumatic Solenoid Valves:



    More Pneumatic Solenoid Valves for you to choose:

    4v1004v210-084v300a1

    *4V100 Pneumatic Valves     *4V200 Pneumatic Valves      *4V300 Pneumatic Valves     *4V400 Pneumatic Valves

    a1 a1 a3pneumatic fast fittings

    *5/2 Way Pneumatic Valve  *5/3 Way Pneumatic Valve       *2/2 Way Pneumatic Valve    *Pneumatic Fast Fitting



    Brando is a Pneumatic Valve manufacturer and exporter in Ningbo, China, which has more than 10 years experience. The most common types are 2/2 way, 3/2 way, 5/2 way and 5/3 way. The valves can be single or double acting (one or two solenoids).


    Brando Supply:
    1. 5/2 Way Pneumatic Solenoid Valve: 4V110-06, 4V120-06, 4V210-06, 4M220-06, 4V210-08, 4V220-08, 4V310-08, 4V320-08, 4V310-10, 4V410-15, 4V420-15, 4M110-06, 4M120-06, 4M210-06, 4M220-06, 4M210-08, 4M220-08, 4M310-08, 4M320-08, 4M310-10, 4M320-10


    2. 5/3 Way Pneumatic Solenoid Valve: 4V130C-06, 4V130E-06, 4V130P-06, 4V230C-06, 4V230E-06, 4V230P-06, 4V230C-08, 4V230E-08, 4V230P-08, 4V330C-08, 4V330E-08, 4V330P-08, 4V330C-10, 4V330E-10, 4V330P-10, 4V430C-15, 4V430E-15, 4V430P-15


    3. 2/2 Way Pneumatic Solenoid Valve: 2V025-06, 2V025-08
