MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer

MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer

    • MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer
    • MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer
    • MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer
    • MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer
  • MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer

    Product Details:

    Place of Origin: China
    Brand Name: Brando
    Certification: CE
    Model Number: BB17540010

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 set
    Price: Negotiation
    Packaging Details: Inner Box, Carton, Pallet
    Delivery Time: 4-8 days
    Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
    Supply Ability: 300000 set per month
    Contact Now
    Detailed Product Description
    Product Name: MP-C-011 Solenoid Valve Coil Voltage: 24VAC, 110VAC, 220VAC, 240VAC (50/60Hz)
    Reference No: 099257-004G,099257-014G, 099257-016D,099257-006G, 099257-009D Connection Type: Flying Leads
    Insulation Class: F Temperatrue Class: T, B
    Application: Henny Penny Pressure Fryer, Deep Fryer Fryer No: MP-944, PFE-500, PFE-500-CFA, PFE-561, PFE-591, PFE-600, PFG-500, PFG-561, PFG-600, PFG-691, CFA-500, CFA-600, Computron 7000, Computron 8000
    High Light:

    Flying Leads Solenoid Valve Coil

    ,

    Deep Fryer Solenoid Valve Coil

    ,

    240V AC Solenoid Coil

    MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer



    This is a MP-C-011 solenoid valve coil, coil feference number: 099257-009-D, 09257-016-D, 099257-004G, 099257-014G, 099257-006G, coil insulation class is F, coil temperature class is T, B, coil connection type is flying leads, supply 24V AC, 110V AC, 120V AC, 220V AC, 230V AC, 240V AC (50/60Hz) voltages, other voltages can be customized. It is used on Henny Penny Genuine fryer MP-944, PFE-500, PFE-500-CFA, PFE-561, PFE-591, PFE-600, PFG-500, PFG-561, PFG-600, PFG-691, CFA-500, CFA-600, Computron 7000, Computron 8000



    Product features of solenoid valve coil:
    1. Using high quality wire which has UL approved;
    2. Using high quality permeablity magnetic material which contain low carbon;
    3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
    4. Insulation class can be B, F, H, N, C;
    5. Protection class can be IP65, IP67 & IP69K;
    6. We also offer special coils like ex-proof coils, water proof coils and so on.
    7. If you have special requirement, pls feel free to contact us.



    Dimension & Data of MP-C-011 solenoid valve coil:

    MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer 0

    Model
    MP-C-011
    Connection Type
    Flying Leads
    Voltage
    24VAC, 110VAC, 220VAC, 240VAC (50/60Hz)
    Insulation Class
    F
    Temperature Class
    T, B
    Coil Ref No



    099257-004G, 099257-014G, 099257-016D,

    099257-006G, 099257-009D

    BAPC216049003

    Model
    BAPC216049003
    Function
    2/2 Way, Normally Closed
    Tube Material
    Stainless Steel
    Shading Ring Material
    Copper
    Seat Type
    Thread
    Fitted Coil
    MP-C-011
    Application Example
    Henny Penny Fryer


    Brando factory production of solenoid valve coil:

    MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer 2



    More Solenoid Valve Coil for you to choose:



    *Connector Options: DIN 43650 Form A, DIN 43650 Form B, DIN 43650 Form C, Wire Leads, DEUTSCH, AMP, KOSTAL .......

    photobank (8)photobank (12)photobank (18)photobank (11)



    *Application Options: Pneumatic Solenoid Valve Coil, Refrigeration Solenoid Valve Coil, Pulse Solenoid Valve Coil, Hydraulic Solenoid Valve Coil, Solenoid Coil For Excavator / Truck / Auto, Injector Rail Solenoid Coil, Solenoid Coil For Home Appliances, LPG CNG Solenoid Coil.........

    photobank (14)photobank (16)photobank (17)photobank (10)



    *Hole Diameter Options: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

    MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer 11MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer 12MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer 13MP-C-011 Solenoid Valve Coil 24V 120V 240V AC For Henny Penny Fryer 14



    Focus on your demands, Offer you best solution:


    √ Contact us if some points you have doubt

    √ Contact us if somewhere need to change
    √ Contact us if not the one you are looking for

    √ Contact us if you are doing designing


    Welcome to your any question and inquiry!
