Goyen Type Solenoid Valve Coil CY123 N282 C53056N QR 24VDC 220VAC

Goyen Type Solenoid Valve Coil CY123 N282 C53056N QR 24VDC 220VAC

Goyen Type Solenoid Valve Coil CY123 N282 C53056N QR 24VDC 220VAC
video
Goyen Type Solenoid Valve Coil CY123 N282 C53056N QR 24VDC 220VAC
Product Details:
Place of Origin: China
Brand Name: Brando
Certification: CE
Model Number: BB12039508
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Inner Box, Carton, Pallet
Delivery Time: 4-8 days
Payment Terms: L/C, T/T, Western Union,Paypal, MoneyGram
Supply Ability: 300000 set per month
Contact Now
Detailed Product Description
Product Name: Goyen Type Solenoid Valve Coil Ref No: CY123, N282, C53056N, QR
Ordering Code: K0300, K0301, K0302, K0303, K0304, K0305, K0306 Connection Type: DIN43650A
Insulation Class: F, H Voltage: 24VDC, 110VAC, 220VAC
Power: 25VA, 20Watt Suitable Valves: Goyen Type Pulse Jet Valves
High Light:

Pulse Valve Solenoid Coil

,

Solenoid Coil For Pulse Valve

,

Pulse Valve Coil

Goyen Type Solenoid Valve Coil CY123 N282 C53056N QR 24VDC 220VAC



This is a CY123 N282 C53056N QR solenoid valve coil for goyen pulse jet valves, coil insulation class is F, H, coil connection type is DIN43650A, 24VDC, 110VAC, 220VAC 50/60Hz voltages, other voltages can be customized. Code No: K0300, K0301, K0302, K0303, K0304, K0305, K0306.



Product features of solenoid valve coil:
1. Using high quality wire which has UL approved;
2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.



Technical data of solenoid valve coil:

Code
Type
Class
Voltage
Inrush
(mA)
Hold
(mA)
Power
K0300
QR
IP64
200/240V 220V AC 50/60Hz
1338/1096
963/716
23.1VA
K0301
QR
IP64
100/120V 110V AC 50/60Hz
234/225
180/152
19.8VA
K0302
QR
IP64
24V AC 50/60Hz
1338/1096
963/716
23.1VA
K0303
QR
IP64
110V DC
212
212
24W
K0304
QR
IP64
48V DC
429
429
20W
K0305
QR
IP64
24V DC
873
873
20W
K0306
QR
IP64
12V DC
1644
1644
20W



Main dimension of solenoid valve coil:

Goyen Type Solenoid Valve Coil CY123 N282 C53056N QR 24VDC 220VAC 0



Brando factory production of solenoid valve coil:

Goyen Type Solenoid Valve Coil CY123 N282 C53056N QR 24VDC 220VAC 1



More Solenoid Valve Coil for you to choose:



*Connector Options: DIN 43650 Form A, DIN 43650 Form B, DIN 43650 Form C, Wire Leads, DEUTSCH, AMP, KOSTAL .......

photobank (8)photobank (12)photobank (18)photobank (11)



*Application Options: Pneumatic Solenoid Valve Coil, Refrigeration Solenoid Valve Coil, Pulse Solenoid Valve Coil, Hydraulic Solenoid Valve Coil, Solenoid Coil For Excavator / Truck / Auto, Injector Rail Solenoid Coil, Solenoid Coil For Home Appliances, LPG CNG Solenoid Coil.........

photobank (14)photobank (16)photobank (17)photobank (10)



*Hole Diameter Options: 5-7mm, 8mm, 9mm, 10mm, 11mm, 12mm, 13mm, 14mm, 15mm, 16mm, 17mm, Up to 60mm.

Goyen Type Solenoid Valve Coil CY123 N282 C53056N QR 24VDC 220VAC 10Goyen Type Solenoid Valve Coil CY123 N282 C53056N QR 24VDC 220VAC 11Goyen Type Solenoid Valve Coil CY123 N282 C53056N QR 24VDC 220VAC 12Goyen Type Solenoid Valve Coil CY123 N282 C53056N QR 24VDC 220VAC 13
